100KVA Diesel Generator 80KW Genset Low Noise Diesel Generator 380V 400V
Price:
Negotiabce
MOQ:
1
Delivery Time:
30work days
Brand:
JIWEI
Product Description
JW-KOFO 80KW 100KVA Soundproof Diesel Generator 50/60Hz Frequency Low Noise 380V/400V
Product Overview
This high-performance soundproof diesel generator delivers reliable power with low noise operation, making it ideal for various industrial and commercial applications.
Product Advantages
Superior Performance
- All-Copper Brushless Generator: Provides excellent conductivity and low loss.
- Efficient Operation: Low fuel consumption and high thermal efficiency ensure long-lasting power and reduced operating costs.
Wide Range of Applications
- Versatile Usage: Suitable as a backup or emergency power source for mines, railways, construction sites, and more.
- Diverse Power Needs: Meets the requirements of factories, hospitals, hotels, schools, and other locations.
Ease of Use and Maintenance
- Elegant Design: Features rainproof and anti-corrosion capabilities, allowing outdoor use without a dedicated machine room.
- User-Friendly Access: Convenient access for adding fuel and battery; includes an emergency stop button for easy operation.
Reliable Product Quality
- High-Quality Components: Constructed from reputable sources, ensuring durability.
- Warranty Support: Backed by a two-year national warranty for after-sales service.
Comprehensive Service System
- Expert Support: An experienced team ready to provide prompt assistance.
- Standardized Processes: Stable pricing and lifetime cost maintenance for wear parts and damages.
Technical Specifications
| Parameter | JW-60 | JW-88 |
|---|---|---|
| Generator set standby power (KVA) | 69 | 110 |
| Generator set standby power (KW) | 55 | 88 |
| Rated power of generator set (KVA) | 63 | 100 |
| Rated power of generator set (KW) | 50 | 80 |
| Rated current (A) | 90 | 144 |
| Unit reference weight (KG) | 825 | 965 |
| Unit reference dimensions (mm) | 1900 * 615 * 1000 | 2100 * 675 * 1222 |
| Engine model | 4MN42-60D | 4MT55-88D |
| Intake method | Pressurization | Pressurization |
| Burning method | Direct spray | Direct spray |
| Cylinder count | 4 | 4 |
| Bore × stroke (mm) | 105 x 120 | 110 x 140 |
| Displacement (L) | 4.15 | 5.32 |
| Compression ratio | 17:1 | 17:1 |
| Main power (kW) | 60 | 88 |
| Rotational speed (r/min) | 1500/1800 | 1500/1800 |
| Maximum idle speed (r/min) | 1575 or less | 1575 or less |
| Minimum no-load stable speed (r/min) | 650 or less | 650 or less |
| Fuel consumption rate (g/kW.h) | 220 or less | 225 or less |
| Crankshaft rotation direction (facing the flywheel) | Counterclockwise | Counterclockwise |
| Cooling methods | Forced water cooling | Forced water cooling |
| Lubrication method | Pressure splash compound | Pressure splash compound |
| Start method | Electric start | Electric start |
| Net mass (kg) | 370 | 480 |
| Cylinder working sequence | The 1-3-4-2 | The 1-3-4-2 |
| Exhaust temperature ℃ | 600 or less | 600 or less |
| Intake pipe diameter mm | 51 | 60 |
| Total oil capacity L | 13 | 15 |
| Maximum oil temperature ℃ | 105 | 105 |
| Oil consumption g/kW.h | 2.04 or less | 1.63 or less |
| Total cooling water capacity L | 18 | 23 |
| Dimensions (including water tank, air filter bracket, excluding air filter and muffler) mm | 1075 * 630 * 938 | 1230 * 675 * 1022 |
| Generator brand | JIWEI | JIWEI |
| Generator model | JW-FDJ50 | JW-FDJ80 |
| Generator rated power (KVA) | 63 | 100 |
| Generator rated power (KW) | 50 | 80 |
| Excitation mode | Brushless excitation | Brushless excitation |
| Frequency (HZ) | 50/60 | 50/60 |
| Power factor | 0.8 Lag | 0.8 Lag |
| Voltage (V) | 380/415 | 380/415 |
| Control system | SmartGen | SmartGen |
Product Images
Our OEM Partners
We collaborate with worldwide famous brands. With our customized solutions consistently delivering satisfaction, we have won an esteemed reputation.
Frequently Asked Questions
Q: What is your MOQ of this item?
A: 1 Sets.
Q: What is the lead time?
A: 7 working days after received the 30% T/T deposit.
Q: Is it all right to make customer's own brand name?
A: We can be your OEM manufacture with your authorization of brand.
Q: Where is your Loading Port?
A: Shanghai or others.
Q: What are your payment terms?
A: 30% TT as deposit, 70% TT before Shipment.
Q: What is your company's available production capacity?
A: 100 Sets per month.
Q: What's the warranty time of diesel generators?
A: 12 months or 1000 working hours, whichever comes first.
Why Choose Jiwei Generator Sets
- Environmental Protection and Fuel Saving: Optimized performance, flexible control, reduced NOx emission, high precision control, low vibration, low noise, and low maintenance cost.
- Delivery Guarantee: Fast delivery time (1-5 days after receiving deposit), 20 years of industry experience with strong supply capabilities and logistics resources.
- Strict Quality Inspection: Each generator undergoes comprehensive testing including 50%, 75%, 100%, and 110% load tests with all control and safety functions verified.
- Service Guarantee: Free technical support, 2-year or 2000-hour warranty, 30-minute response time, global warranty coverage, and spare parts availability.
- Customized Services: Custom products and branding available according to your specific requirements.
- Confidentiality: Quality assurance and confidentiality agreements available for stable cooperation.
For more specifications or custom requirements, please contact us.
