LG-PRO 20W RAYCUS High-Performance Air Cooling Fiber Laser Marking Machine for Metal Plastic New DXF AI Graphic Format Supported
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
Negotiable
Product Description
Product Description
Specification
Parameter Category | Specifications |
Model | HGGH-LG20 |
Laser Source | RAYCUS Fiber Laser |
Central Wavelength | 1064 nm |
Output Power | Nominal Average: 20W |
Pulse Repetition Rate | 30~60 kHz |
Scanning Speed | ≤7000 mm/s |
Focusing Lens | Standard: F=160 mm |
Optional: F=100 mm / F=210 mm / F=254 mm | |
Marking Area | F=100 mm: 70×70 mm |
F=160 mm: 105×105 mm | |
F=210 mm: 140×140 mm | |
F=254 mm: 170×170 mm | |
Marking Precision | Standard Line Width: 0.06 mm (material-dependent) @F=160 mm |
Min. Character Height: 0.2 mm @F=160 mm | |
Cooling Method | Air-cooled |
Control System | Industrial PC + LCD Display |
Vision Monitoring | HD Camera for real-time marking inspection |
Lifting Mechanism | Motorized/Manual lifting, Stroke: 300 mm |
Power Supply | 500W / AC220V / 50Hz |
Voltage Tolerance: ±5% (Stabilizer required if exceeded) | |
Grounding | Compliant with National Standard GB |
Ambient Temperature | 0~40°C (Air conditioning required if exceeded) |
Ambient Humidity | 30%≤RH≤85% (Risk of condensation if exceeded) |
Environment Cleanliness | Oil contamination: Not permitted |
Condensation: Not permitted | |
Compressed Gas | Optional: 0.5~0.7 MPa clean air (free of moisture/oil residue) |
Wuhan HGGuanghe Technology Co., Ltd
Located in Wuhan’s East Lake High-Tech Development Zone (China (Hubei) Pilot Free Trade Zone), is a wholly-owned subsidiary of Wuhan Huagong Laser Engineering Co., Ltd., part of HGTECH (Stock Code: 000988), a leading listed national high-tech enterprise.
Backed by a leading enterprise in China's laser equipment manufacturing industry
Huagong Laser (HGTECH) specializes in high-power cutting systems, precision micro-processing solutions, and laser source exports. Awarded the National Science and Technology Progress Award, the company leads the high-end laser equipment market globally.
