Hot Sale 30w Cabinet CO2 Laser Marking Machine Non Metal Co2 Laser Engraving Machine Laser Marker for Wood Leather Acrylic
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
Negotiable
Product Description
Product Description
Specification
Product Model | GH-30C |
Laser Center Wavelength | 10.6 μm |
Nominal Average Output Power | 30 W |
Pulse Repetition Frequency | 0–25 kHz |
Scanning Speed | F=150MM,≤7000 MM/S |
Focus Lens | Standard: F=150 mm Optional: F=200 mm / F=250 mm |
Marking Range | 107×107 mm 140×140 mm (with optional lens) 175×175 mm (with optional lens) |
Standard Line Width | 0.1 mm (material-dependent, @F=150 mm) |
Minimum Character Height | 0.4 mm (@F=150 mm) |
Cooling Method | Air Cooling |
Industrial Control Computer (IPC) | Enterprise-grade IPC with LCD monitor |
Lifting Mechanism | Manual lift, nominal stroke: 300 mm |
System Power Supply | 1 kW / AC 220 V / 50 Hz ±5% (Voltage stabilizer required beyond range) |
Grounding Requirement | Class D (Grounding resistance ≤1000 Ω) |
Ambient Temperature | 5–40°C (Air conditioning required beyond range) |
Ambient Humidity | Non-condensing |
Oil Contamination Tolerance | Prohibited |
Condensation Resistance | Prohibited |
Compressed Gas (Not Included as Standard) | 0.5–0.7 MPa, oil/moisture-free |
Wuhan HGGuanghe Technology Co., Ltd
Located in Wuhan’s East Lake High-Tech Development Zone (China (Hubei) Pilot Free Trade Zone), is a wholly-owned subsidiary of Wuhan Huagong Laser Engineering Co., Ltd., part of HGTECH (Stock Code: 000988), a leading listed national high-tech enterprise.
Backed by a leading enterprise in China's laser equipment manufacturing industry
Huagong Laser (HGTECH) specializes in high-power cutting systems, precision micro-processing solutions, and laser source exports. Awarded the National Science and Technology Progress Award, the company leads the high-end laser equipment market globally.
