Aluminum 3 Position Pneumatic Rotary Actuator 90 Degree Pneumatic Rotary Valve Actuator
Price:
10-2000USD
MOQ:
1pcs
Delivery Time:
3-7 days
Brand:
OEM
Product Description
Aluminum 3 Position Pneumatic Rotary Actuator 90 Degree Pneumatic Rotary Valve Actuator
Rack And Pinion Three Position Pneumatic Rotary Actuator
Pneumatic Actuator Specifications
| Material | Extruded Aluminum alloy |
|---|---|
| Rotary Angle | 0~90 degree |
| Structure | Rack and pinion rotary actuator |
| Working Pressure | 2~8bar |
| Surface Treatment | Hard anodizing |
| Working Temperature | Normal Temperature: -20ºC(-4°F) ~ 80ºC (+176°F) High Temperature: -15ºC(+5°F) ~ 150ºC (+302°F) Low Temperature: -40ºC(-104°F) ~ 80ºC (+176°F) |
| Connection | NAMUR, ISO5211 and DIN3337 |
| Application | Ball valve, butterfly valve, and rotary machine |
| Cup Color | Grey, black, sky blue, dark blue, red, orange |
AT Series Pneumatic Actuators Features
- Conforms to ISO5211, DIN3337, VDINDE-3854, and NAMUR specifications
- Extruded high-intensity aluminum body with hard anodized coating for durability
- Low friction coefficient and swift performance
- Compact, modern construction with multiple specifications
- High-quality bearings for low friction, long cycle life, and quiet operation
- External stroke adjustment bolts for precise ±5° adjustment
- Available in double acting and single acting (Spring-Return) models
- Multi-function indicator with NAMUR for easy accessory mounting
- Pre-compressed load spring for safe installation and removal
- Die-cast aluminum pistons and end caps for strength and light weight
- Various O-ring materials available for different temperature ranges
- Direct solenoid valve mounting without connecting plank
Main Features
- Ideal for ball valves and butterfly valves
- Cost-effective, compact design with long service life
- Available in single acting (spring return) or double acting models
- Color options: orange, blue, black, dark gray (OEM colors available)
- Working pressure: 0.3~0.8MPa
- Bottom connection: ISO 5211
- Solenoid valve standard: Namur
- Compatible accessories: limit switch box, solenoid valve, positioner
Pneumatic Actuator Dimension
Product Application
AT series Pneumatic Actuator features dual pistons driven by racks and pinions. Available in Dual Acting and Spring Return models, suitable for various environments including flammable, corrosive, dusty, strong magnetic field, radiation, and vibration conditions. Ideal for both indoor and outdoor applications.
Applications include auto-control systems in electric power, petrochemical, metallurgy, petroleum, gas, construction, drainage, chemical industry, oil refining, mining, power plants, architecture, medicine, food, gas, and scientific research fields.
