Double Acting 3 Position Rotary Actuator Rack And Pinion Aluminum Pneumatic Actuators
Price:
10-2000USD
MOQ:
1pcs
Delivery Time:
3-7 days
Brand:
OEM
Product Description
Double Acting 3 Position Rotary Actuator Rack And Pinion Aluminum Pneumatic Actuators
3 Position Double Acting Aluminum Pneumatic Actuator
High-performance 3-way pneumatic rotary actuator designed for precision control in industrial applications.
Pneumatic Actuator Specifications
| Material | Extruded Aluminum alloy |
|---|---|
| Rotary Angle | 0~90 degree |
| Structure | Rack and pinion rotary actuator |
| Working Pressure | 2~8bar |
| Surface Treatment | Hard anodizing |
| Working Temperature | Normal Temperature: -20ºC(-4°F) ~ 80ºC (+176°F) High Temperature: -15ºC(+5°F) ~ 150ºC (+302°F) Low Temperature: -40ºC(-104°F) ~ 80ºC (+176°F) |
| Connection | NAMUR, ISO5211 and DIN3337 |
| Application | Ball valve, butterfly valve, and rotary machine |
| Cup Color | Grey, black, sky blue, dark blue, red, orange |
Product Features
- Conforms to ISO5211, DIN3337, VDINDE-3854, and NAMUR standards
- Extruded high-intensity aluminum body with hard anodized coating
- Low friction coefficient for swift performance and long life
- Compact construction with multiple specifications
- High-quality bearings for low friction, high cycle life, and silent operation
- External stroke adjustment bolts (±5° adjustment)
- Available in double acting and single acting (Spring-Return) models
- Multi-function indicator with NAMUR for easy accessory mounting
- Pre-compressed load spring for safe mounting and tear down
- Die-casting aluminum pistons and end caps for high intensity and light weight
- Various O-ring materials available for different temperature ranges
Key Benefits
- Ideal for ball valve and butterfly valve applications
- Cost-effective solution with compact design
- Long working life with minimal maintenance
- Available in orange, blue, black, dark gray (OEM colors available)
- Working pressure: 0.3~0.8MPa
- Bottom connection: ISO 5211
- Solenoid valve standard: Namur
- Compatible with accessories: limit switch box, solenoid valve, positioner
Pneumatic Actuator Dimension
Product Applications
AT series Pneumatic Actuator features dual pistons driven by racks and pinions, available in Dual Acting and Spring Return models. Suitable for various environments including flammable, corrosive, dusty, strong magnetic field, radiation, and vibration conditions.
Ideal for auto-control applications in:
- Electric power plants
- Petrochemical industry
- Metallurgy and mining
- Oil and gas processing
- Water treatment and drainage systems
- Chemical processing plants
- Food and pharmaceutical industries
- Scientific research facilities
