Mimaki JFX500-2131 Large Format UV LED Flatbed Printer - 2100x3100mm Print Area, 60m²/h Speed
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
7-15 Working Days
Brand:
Mimaki
Product Description
High-Speed Large Format UV LED Flatbed Printer
The Mimaki JFX500-2131 combines exceptional speed with superior print quality, delivering maximum productivity for industrial printing applications.
Key Performance Advantages
Maximum Speed & Efficiency
Achieves maximum print speed of 60 m²/h with full-color printing capability.
Premium Print Quality
Advanced head control technology ensures exceptional high-resolution output at 300dpi, 600dpi, 900dpi, and 1,200dpi settings.
Enhanced Reliability
White ink circulation system and integrated degassing module provide consistent operation stability.
User-Friendly Operation
Intuitive control interface and easy-to-understand command functions.
Eco-Conscious Design
Long-lasting UV LED technology reduces power consumption, while 2-liter refillable ink stations minimize waste.
Technical Specifications
| Model | JFX500-2131 |
| Print Head | On-demand Piezo head (6 printheads with 3 staggered configuration) |
| Print Resolution | 300dpi, 600dpi, 900dpi, 1,200dpi |
| Ink Types | UV curable ink: LUS-120 (C, M, Y, K, W, Cl), LUS-150 (C, M, Y, K, W), LUS-200 (C, M, Y, K, W), LH-100 (C, M, Y, K, W, Cl), PR-100, PR-200 (Primer) |
| Supply System | 2L Ink Station |
| Maximum Print Size | 2,100 × 3,100 mm (82.7 × 122.0") |
| Media Height | Max. 50 mm (2.0") |
| Print Accuracy | ± 0.3 mm or ± 0.3% from specified print distance |
| UV LED Lifetime | Approximately 5,000 hours |
| Power Requirements | AC 200-240 V, 50/60 Hz, Less than 2.4 kVA |
| Dimensions | 4,100 × 4,462 × 1,490 mm (161.4 × 175.7 × 58.7") |
| Weight | 1,353 kg (2,982.8 lbs) |
| Certifications | VCCI class A, CE Marking, CB Report, UL, RoHS Directive |
Software Integration
