MIMAKI JFX600-2513 UV LED Flatbed Inkjet Printer 2500x1300mm 200m²/h 600-1200dpi
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
7-15 Working Days
Brand:
MIMAKI
Product Description
MIMAKI JFX600-2513 UV-LED Large Flatbed Inkjet Printer
High-Speed Industrial Printing Solution
Successor to the JFX500-2131, this large-format flatbed UV inkjet printer delivers exceptional speed and quality for demanding industrial applications.
Key Performance Features
- Maximum print speed: 200 m²/h for high-volume production
- Print resolution: 600 dpi and 1,200 dpi for superior image quality
- 16 on-demand piezo printheads in 4×4 staggered layout
- Large format capacity: 2,500 × 1,300 mm maximum diagram dimensions
Technical Specifications
| Print Head | On-demand Piezo head 16 printheads (4×4 lines in staggered layout) |
|---|---|
| Print Resolution | 600 dpi, 1,200 dpi |
| Ink Systems |
Flexible UV curable ink: LUS-120 (C, M, Y, K, Lc, Lm, W, Cl) Flexible UV curable ink: LUS-150 (C, M, Y, K, Lc, Lm, W) Flexible UV curable ink: LUS-211 (C, M, Y, K, W, Cl) Hard UV curable ink: LH-100 (C, M, Y, K, Lc, Lm, W, Cl) Primer: PR-200 |
| Ink Supply | 1-liter bottles for each color White ink circulation using Mimaki Circulation Technology (MCT) |
| Media Handling |
Dimensions: Up to 2,500 × 1,300 mm (98.4 × 51.2") Height: Maximum 60 mm Weight: Less than 50 kg/m² Absorption: Blower adsorption type + foot switch Partitions: 2 partitions (X-axis direction) |
| Curing System | LED-UV system |
| Interface | Ethernet 10GBASE-T |
| Safety Standards | UL 775 ETL / CE Marking (EMC, Machinery directive, RoHS) / REACH / EAC |
| Power Requirements |
Single phase, AC200-240V±10%, 50/60Hz±1Hz, 24 A ×3 Power consumption: Each INLET less than 4.8 kVA |
| Installation Environment |
Temperature: 20-30°C (68-86°F) Relative humidity: 35-65% Rh (Non-condensing) Accuracy maintained temperature: 20-25°C (68-77°F) Temperature gradient: Less than ±10°C/h (±18°F/h) Dust: Similar to standard office environments |
| Physical Dimensions |
Assembled: Approx. 5,300 × 2,850 × 1,700 mm (208.7 × 112.2 × 66.9") or less Weight: Approx. 1,200 kg (2,645.5 lbs.) or less |
Production Applications
Irregular Shapes
Furniture
Furniture
Display Case
Indoor Advertisement
Outdoor Advertisement
Bathroom
Wall Display
