National Instruments RF Multiplexer Switch Module PXI-2596 6 Channels High Performance
Price:
$10,000/sets >=1 sets
MOQ:
one
Delivery Time:
Delivery time for minimum order quantity ≤ 30 days
Brand:
National Instruments
Product Description
Customized Support National Instruments PXI-2596 PXI RF Multiplexer Switch Module
The National Instruments PXI-2596 (Part Number: 778572-96) is a multiplexer, SPDT relay, and transfer switch module designed for routing RF or microwave signals in automated test applications. The PXI-2596 provides a 26.5 GHz switching solution in various PXI configurations, integrating the entire switching solution on a single platform.
Key Features
- Utilizes Radiall microwave relays for superior performance
- Insertion loss below 1 dB at 26.5 GHz, minimizing impact on test framework
- Ideal for routing high-order harmonics from RF upconverters or different sources to RF downconverters
- Compatible with NI PXI-5671 2.7 GHz Vector Signal Generator and NI PXI-5660 2.7 GHz Vector Signal Analyzer
- Configurable through NI Switch Executive 2.1 software
Technical Specifications
| Specification | Value |
|---|---|
| Bus Connector | PXI Hybrid |
| Maximum AC Switching Voltage | 90 V |
| Relay Type | Electromechanical |
| Switching Bandwidth | 26.5 GHz |
| Characteristic Impedance | 50 Ω |
| Maximum Insertion Loss | -0.3 dB |
| Number of Channels | 6 |
| Number of Groups | 2 |
| Termination | None |
Software Integration
Engineers can configure and control the NI PXI-2596 RF Multiplexer Switch Module using NI Switch Executive 2.1, which provides enhanced functionality for Excel, RF switching, and switch system troubleshooting. The software enables automatic access to settings for each switch path, allowing storage of RF path calibration and parameter data to improve overall test system accuracy.
The new configuration programming interface allows experts to define and arrange their NI Switch Executive virtual devices from any programming environment, including NI TestStand test management software, NI LabVIEW graphical development environment, NI LabWindows/CVI ANSI C development software, and Microsoft Excel. Existing switch path records created in Excel can be imported into the NI Switch Executive environment for easier maintenance and adjustment.
