High Strength Kevlar Aramid Rope 1000lbs Tensile Strength Kevlar Aramid Yarn
Price:
USD 350
MOQ:
1 roll
Delivery Time:
within 5 days
Brand:
Vibran
Product Description
Kevlar Aramid Rope for Glass Tempering Furnace - High Temperature Resistant
Our Kevlar aramid rope is a high-performance transmission and load-bearing component specifically designed for glass tempering furnaces. Crafted with premium Kevlar aramid fiber as the core material, it integrates exceptional heat resistance, tensile strength, and durability, perfectly adapting to the high-temperature, high-load working environment of glass tempering equipment.
Core Features
- Outstanding High-Temperature Resistance: Withstands continuous operating temperatures up to 260°C and short-term exposure to higher temperatures.
- Superior Tensile Strength: Reinforced with high-strength Kevlar aramid fiber, boasting excellent load-bearing capacity.
- Exceptional Durability & Wear Resistance: Features strong abrasion resistance and fatigue resistance for long-term use.
- Stable Performance & Low Maintenance: Maintains stable dimensional stability in harsh conditions, reducing maintenance costs.
- Corrosion & Chemical Resistance: Resists erosion from common industrial chemicals, moisture, and humidity.
Product Specifications
| Item | Specification |
|---|---|
| Material | 100% Kevlar Aramid Fiber |
| Continuous Operating Temperature | -50°C ~ 260°C |
| Short-Term Peak Temperature | Up to 300°C |
| Diameter Range | 2mm - 20mm (Customizable) |
| Standard Length | 250m/roll, 500m/roll (Custom lengths available) |
| Color | Standard: Yellow (Custom colors for bulk orders) |
| Braiding Structure | 8-strand, 12-strand (Customizable) |
| Tensile Strength | ≥ 2800 N/mm² |
| Elongation at Break | ≤ 3.5% |
| Wear Resistance | Excellent (Passes 5000+ hours of friction testing) |
| Chemical Resistance | Resists acids, alkalis, and common industrial solvents |
|
Flat Rope Size (Can be customized) |
||
|
Model |
Width (mm) |
Thickness (mm) |
|
8 x 3 |
8 |
3 |
|
8 x 4 |
8 |
4 |
|
10 x 3 |
10 |
3 |
|
10 x 4 |
10 |
4 |
|
10 x 5 |
10 |
5 |
|
12 x 3 |
12 |
3 |
|
12 x 3.5 |
12 |
3.5 |
|
12 x 4 |
12 |
4 |
|
12 x 4.5 |
12 |
4.5 |
|
12 x 5 |
12 |
5 |
|
12 x 5.5 |
12 |
5.5 |
|
13 x 2 |
13 |
2 |
|
13 x 3 |
13 |
3 |
|
13 x 3.5 |
13 |
3.5 |
|
Square Rope Size (Can be customized) |
||
|
Model |
Width (mm) |
Thickness (mm) |
|
4 x 4 |
4 |
4 |
|
5 x 5 |
5 |
5 |
|
5.5 x 5.5 |
5.5 |
5.5 |
|
6 x 6 |
6 |
6 |
|
8 x 8 |
8 |
8 |
|
10 x 10 |
10 |
10 |
|
12 x 12 |
12 |
12 |
|
Round Rope Size (Can be customized) |
||
|
Dia 2mm |
Dia 3mm |
Dia 4mm |
|
Dia 5mm |
Dia 6mm |
Dia 8mm |
|
Dia 10mm |
Dia 12mm |
Dia 20mm |
Specialized for glass tempering furnaces, including flat glass tempering furnaces, curved glass tempering furnaces, and ultra-thin glass tempering equipment. Widely used in transmission systems, load-bearing mechanisms, and guiding components of tempering furnaces.
Why Choose Our Kevlar Aramid Rope?
- Equipment-Specific Design: Tailored to the working characteristics of glass tempering furnaces.
- Premium Material Selection: High-quality Kevlar aramid fiber from reputable suppliers.
- Customization Support: Flexible customization of diameter, length, and structure.
- Strict Quality Control: Rigorous testing for tensile strength, heat resistance, and wear resistance.
Installation & Usage Notes
- Pre-Installation Check: Inspect the rope for any damage before installation.
- Proper Tensioning: Maintain moderate tension to prevent breakage or slippage.
- High-Temperature Protection: Do not expose to temperatures exceeding 300°C for extended periods.
- Avoid Sharp Edges: Ensure the rope contacts smooth surfaces only.
- Regular Inspection: Check monthly for wear, elongation, or deformation.
- Storage Conditions: Store in a dry, cool, and well-ventilated area.
Packing and Shipping
The Kevlar Aramid Ropes are packed in strong, durable cardboard boxes with a protective inner lining. The boxes are clearly labeled with the product name and specifications. For shipping, the boxes are securely wrapped in plastic and placed in sturdy wooden crates.
