96 Ports 32GB/S Brocade G630 Fibre Channel Switch For Data Centers
Price:
US $ 11000 -20000/ pieces
MOQ:
1 pieces
Delivery Time:
Negotiable
Brand:
Brocade
Product Description
Brocade G630 Fibre Channel Switch
96-port high-performance Fibre Channel switch designed for data center environments, supporting 32GB/s speeds with advanced switching capabilities.
Performance Features
Bandwidth: 4Tb/s
Power Efficiency: 0.23 watts/Gb/s, dual hot-swappable power supplies
Physical Dimensions: 440.0mm (W) × 86.70mm (H) × 609.60mm (D)
Advanced Capabilities
- Frame-based ISL trunking: 256 Gb/s (optional)
- Fabric scalability: Single fabric supports 56 domains, 7 hops; MPR fabric supports 19 hops
- High-quality construction for reliable data center operation
Fibre Channel Performance
Supported Speeds: 4.25, 8.5, 14.025, 28.05 Gbps line speeds (full duplex)
Auto-sensing: 4, 8, 16, and 32 Gbps port speeds
QSFP Port Support: 4×32, 4×16, 4×8, 4×4 Gbps speeds (requires Brocade FOS v8.2.0)
Maximum Latency: <780 ns for locally switched ports, 2.6 µs between port groups
Routing Performance: Cut-through routing at 32G between locally switched groups
Encryption/Compression: 1 µs per node
Key Specifications
| Specification | Details |
|---|---|
| Product Status | In Stock |
| Port Configuration | 48 Port Activation (default) |
| Communication Mode | Full-Duplex |
| Model Number | G630 |
| Origin | China |
| Product Lifecycle | Active |
