24 12 Port Fibre Channel Switch Includes 12 16Gb/S Shortwave SFP SX CFW Core Switch
Price:
$5,250 -5600/ piece
MOQ:
1 pieces
Delivery Time:
Negotiable
Brand:
Brocade
Product Description
24/12-Port Activation Network Switch BR-6505-12-16G-0R
The Brocade® 6505 Switch with Gen 5 Fibre Channel provides exceptional price/performance value, combining flexibility, simplicity, and enterprise-class functionality in an entry-level switch. Designed to enable maximum flexibility and reliability, the Brocade 6505 is configurable in 12 or 24 ports and supports 2, 4, 8, or 16 Gbps speeds in an efficiently designed 1U package. It comes standard with a single power supply with integrated fans. A second, optional power supply provides additional redundancy for increased resiliency.
Technical Specifications
| Model Number | switch ethernet fiber optic BR-6505-12-16G-0R |
|---|---|
| Ports | 24 |
| Communication Mode | Full-Duplex |
| Lifecycle | Active |
| Frame buffers | 8,192 dynamically allocated |
| Classes of service | Class 2, Class 3, Class F (inter-switch frames) |
| Access Gateway | Supports |
| Data traffic types | Fabric switches supporting unicast |
| Heat dissipation | 24 ports at 338 BTU/hr |
| Input line frequency | 47 Hz to 63 Hz |
| Size | Width: 437.64 mm (17.23 in.) Height: 43.18 mm (1.7 in.) Depth: 443.23 mm (17.45 in.) |
| Vibration | Operating: 0.5 g sine, 0.4 grms random, 5 Hz to 500 Hz Non-operating: 2.0 g sine, 1.1 grms random, 5 Hz to 500 Hz |
| Supported management software | HTTP, SNMP v1/v3 (FE MIB, FC Management MIB), SSH; Auditing, Syslog; Brocade Advanced Web Tools; Brocade Network Advisor SAN Enterprise or Brocade Network Advisor SAN Professional/Professional Plus; Command Line Interface (CLI); SMI-S compliant; Administrative Domains; trial licenses for add-on capabilities |
Product Advantages
Our Exhibition
Packing & Delivery
Why Choose Us
How can we guarantee quality?
✅ Strict Quality Control Process
What can you buy from us?
- Brocade FC & Ethernet Switches (e.g., Brocade 6505, 6510, G620)
- QLogic & Emulex HBAs (e.g., QLogic 2562, Emulex LPe31000)
- Finisar Optical Transceivers (10G/25G/40G/100G, compatible with Cisco, HPE, etc.)
- Mellanox InfiniBand & Ethernet Adapters (e.g., ConnectX-3/4/5, 10G/25G/100G)
Why should you buy from us not from other suppliers?
- ✅ Genuine & Reliable Products
- ✅ Competitive Pricing
- ✅ Fast & Secure Shipping
- ✅ Technical Support
- ✅ Flexible Solutions
