BR-6510-24-16G-R Brocade San Switch 16Gb Activated 24-16Gb/S Short Wave SFP Aruba Server Switch
Price:
$7,993 -1000/ piece
MOQ:
1pieces
Delivery Time:
Negotiable
Brand:
Brocade
Product Description
Brocade San Switch BR-6510-24-16G-R 16Gb 48 Port
The Brocade® 6510 Switch meets the demands of hyper-scale, private cloud storage environments by delivering market-leading Gen 5 Fibre Channel technology and capabilities that support highly virtualized environments. Designed to enable maximum flexibility and reliability, the Brocade 6510 is a high-performance, enterprise-class switch configurable in 24, 36, or 48 ports. It supports 2, 4, 8, 10, or 16 Gbps speeds in an efficiently designed 1U package.
- Enables fast, easy, and cost-effective scaling from 24 to 48 ports
- Leverages Brocade Fabric Vision technology's powerful monitoring, management, and diagnostic tools to simplify administration, increase uptime, and reduce costs
- Helps pinpoint problems faster and simplify SAN configuration and management with Brocade Network Advisor
- Simplifies deployment with the Brocade EZSwitchSetup wizard and supports high-performance fabrics by using Brocade ClearLink D_Ports to identify optic and cable issues
- Maximizes availability with redundant, hot-pluggable components and non-disruptive software upgrades
| Model Number | fiber optic ethernet switch Brocade 6510 BR-6510-24-16G-R |
| Ports | 48 |
| Communication Mode | Full-Duplex |
| Fibre Channel ports | Switch mode (default): 24-, 36-, and 48-port configurations (12-port increments through Ports on Demand [PoD] licenses); E, F, M, D, EX ports Brocade Access Gateway default port mapping: 40 F_Ports, 8 N_Ports |
| Scalability | Full fabric architecture with a maximum of 239 switches |
| Certified maximum | 6,000 active nodes; 56 switches, 19 hops in Brocade Fabric OS® fabrics; larger fabrics certified as required |
| Maximum fabric latency | Latency for locally switched ports is 700 ns; encryption/compression is 5.5 µsec per node; Forward Error Correction (FEC) adds 400 ns between E_Ports (enabled by default). |
| Enclosure | Front-to-back airflow; power from back, 1U Back-to-front airflow; power from back, 1U |
| Size | Width: 437.64 mm (17.23 in.) Height: 43.18 mm (1.7 in.) Depth: 443.23 mm (17.45 in.) |
| System weight | 9.16 kg (20.20 lb) with two power supply FRUs, without transceivers |
| Operating environment | Temperature: 0°C to 40°C/32°F to 104°F Humidity: 10% to 85% (non-condensing) |
| Power supply | Dual, hot-swappable redundant power supplies with integrated system cooling fans |
| DC power consumption | 112 W with all 48 ports populated with 16 Gbps SWL optics 53 W for empty chassis with no optics |
Product Advantages
Our Exhibition
Packing & Delivery
FAQ
Q: Are you trading company or manufacturer?
A: We are manufacturer.
Q: How long is your delivery time?
A: Generally it is 2-5 days if the goods are in stock. or it is 10 days if the goods are not in stock, it is according to quantity.
Q: Can you offer a better price? Any discount?
A: Yes we can give you discount. But it is based on quantity. More quantity more attractive price.
Q: What is your warranty period?
A: 1. Different products have different warranties. 2. Comprehensive after-sales service, including quality service, guidance services, We focus on customer needs in every detail. Please contact us if you need our detail warranty term.
Q: What's the package?
A: Original packing. For the outside, we will pack it in an empty box to protect from damaged during transportation, and ensure you will receive the goods in good condition.
