QSFP112 400GBASE-DR4 Optical Module With PAM4 1310nm Wavelength For Data Transmission
Price:
$974-1115 / piece
MOQ:
1 pieces
Delivery Time:
Negotiable
Brand:
Hengzheng TC
Product Description
Mellanox 400GBASE-DR4 QSFP112 NDR InfiniBand Single-mode Optical Module
Product Description
The Mellanox MMA1T00-HS compatible QSFP56 HDR InfiniBand optical transceiver is a 200Gb/s single-port QSFP56, SR4 multimode parallel transceiver, using a single 4-channel MPO-12/UPC optical connector. The parallel multimode, short distance 4-channel (SR4) operates with 50G-PAM4 modulation, and the maximum fiber transmission time is 100ms when using 4 multimode fibers. It is qualified for use in HDR InfiniBand end-to-end systems, for Quantum switches and ConnectX-6 HCA.
Key Features
- Complies with InfiniBand NDR end-to-end system requirements
- Built-in Macom chip, with a maximum power consumption of 10W
- Support the connection of 800G to 2x400G links from switch to network card
- Support 1/2 rate configuration for 200G (2x 100G)
- Convert 4 sets of 106.25G PAM4 electrical signals into parallel transmission of 400GAUI-4 electrical signals
- Complies with the hot-swappable QSFP112 standard
- Complies with QSFP-112 MSA, CMIS Rev 5.0, IEEE 802.3ck standards and Class 1 laser safety
|
Encapsulation
|
QSFP112
|
|
Wavelength
|
1310nm
|
|
Joggle/interface
|
MPO-12 (APC)
|
|
Emitter type
|
EML
|
|
Transmit power
|
-2.9~4.0dBm
|
|
Power budget
|
3dB
|
|
Power consumption
|
10W
|
|
DDM/DOM
|
Support
|
|
Modulation (electrical port)
|
4x100G-PAM4
|
|
DSP
|
Transmitting and receiving
|
|
Core size
|
G.652/9um
|
|
Technical protocol
|
IEEE Std 802.3ck, QSFP112 MSA, CMIS 5.0
|
|
Maximum transmission rate
|
425Gbps (4x106.25Gb/s)
|
|
Maximum transmission distance
|
500m
|
|
Optical fiber type
|
Single mode
|
|
Receiver type
|
PIN
|
|
Minimum received power
|
-5.9dBm
|
|
Receiving overload
|
4.0dBm
|
|
Extinction ratio
|
>3.5dB
|
|
Commercial temperature range
|
0~70°C (32~158°F)
|
