BOE EV101WUM N85 10.1 Inch TFT LCD Module with 1000 cd/m² Brightness 1920x1200 WUXGA Resolution and LVDS 45 Pin Interface

This BOE EV101WUM-N85 10.1 inch TFT LCD module features 1920x1200 WUXGA resolution, LVDS 45 pin interface and normally black display mode. It supports 16.7M colors, 72% NTSC color gamut, 1000 cd/m² typical brightness, 900:1 typical contrast ratio and 80/80/80/80 typical viewing angle performance. With 9S4P LED backlight structure, wide operating temperature range and industrial-grade display performance, it is suitable for industrial control systems, outdoor-readable terminals, medical equipment, testing instruments and embedded display applications. Customization is available for brightness, interface, touch panel, FPC structure, cover lens and other specifications based on different project requirements.

• BOE 10.1 inch TFT LCD module with 1920x1200 WUXGA resolution
• LVDS 45 pin interface for industrial display controller systems
• 1000 cd/m² typical high brightness for outdoor-readable equipment use
• 72% NTSC color gamut for better image and interface display performance
• Normally black display mode with 900:1 typical contrast ratio
• 80/80/80/80 typical viewing angle for stable visual performance
• Wide temperature range from -20℃ to +70℃ for industrial applications
• Customization support for brightness, touch panel, FPC and cover lens design

• Industrial HMI control panels requiring high resolution LCD modules
• Outdoor-readable equipment screens and semi-outdoor display terminals
• Medical equipment displays requiring 10.1 inch WUXGA panels
• Testing instruments and measurement device screens
• Smart factory monitoring terminals with LVDS controller boards
• Custom embedded display projects requiring high brightness 1920x1200 screens
