This BOE 12.2 inch TFT LCD module features 1920x1200 WUXGA resolution, LVDS interface and normally black display mode. It supports 16.7M colors, 1000 cd/m² typical brightness, 1000:1 typical contrast ratio, 85% NTSC typical color gamut and 89/89/89/89 typical viewing angle performance. With Fine AG surface treatment, 8S6P LED backlight structure and wide operating temperature range, it is suitable for industrial control systems, outdoor-readable terminals, medical equipment, testing instruments and embedded display applications. Customization is available for brightness, interface, touch panel, FPC structure, cover lens and other specifications based on different project requirements.

• BOE 12.2 inch TFT LCD module with 1920x1200 WUXGA resolution
• LVDS 45 pin interface for industrial display controller systems
• 1000 cd/m² typical high brightness for outdoor-readable equipment use
• 85% NTSC typical color gamut for better image and UI display performance
• Fine AG surface with 25% haze and 3H hardness for industrial applications
• 89/89/89/89 typical viewing angle for stable visual performance
• Wide temperature range from -20℃ to +70℃ for demanding environments
• Customization support for brightness, touch panel, FPC and cover lens design

• Industrial HMI control panels requiring high brightness WUXGA LCD modules
• Outdoor-readable or semi-outdoor equipment display terminals
• Medical equipment screens requiring 12.2 inch high resolution panels
• Testing instruments and measurement device display interfaces
• Smart factory monitoring terminals with LVDS controller boards
• Custom embedded display projects requiring 1000 nits 1920x1200 screens
