12000 Lumen WUXGA Resolution 3LCD Laser Projector with 360° Installation for Large Venue Projection
Price:
Negotiable
MOQ:
1pc
Delivery Time:
5-20days
Brand:
SMX
Product Description
12000 Lumen 3LCD Laser Projector
The SMX MX-X12000U is a versatile 3LCD Laser Projector delivering 12,000 lumens of brightness for large venue applications. Featuring advanced laser light technology and a sealed optical engine with filter-less design, this projector offers exceptional color reproduction, low maintenance, and quiet operation.
Key Features
- 12,000 Lumen High Brightness with Vivid Colors
- Support for 4K High-definition Input
- Advanced Keystone Correction for Installation Flexibility
- 20,000 Hours Ultra-long Life Laser Light Source
- Centralized LAN Control for Efficient Management
- Built-in HDBaseT Support
Application Areas
- Large Venue Projection
- Immersive Room Environments
- 3D Mapping Projection
- Exhibition & Museum Projection
Advanced Installation Features
Lens Shift Capability
The MX-X12000U allows lossless panning of the image through menu controls. Maximum vertical adjustment: 50% upward, 10% downward. Maximum horizontal adjustment: ±20%.
The MX-X12000U allows lossless panning of the image through menu controls. Maximum vertical adjustment: 50% upward, 10% downward. Maximum horizontal adjustment: ±20%.
360° Flexible Installation
Supports full 360° projection capability with lossless image translation through menu adjustments for easy positioning.
Supports full 360° projection capability with lossless image translation through menu adjustments for easy positioning.
Built-In HDBaseT Support
Enables real-time transmission of high-definition signals up to 100 meters, simplifying engineering wiring and improving system stability in complex installation environments.
Enables real-time transmission of high-definition signals up to 100 meters, simplifying engineering wiring and improving system stability in complex installation environments.
Advanced Keystone Correction
Comprehensive correction options including horizontal & vertical keystone, hexagonal correction, pincushion, barrel distortion correction, and multi-point keystone correction for optimal imaging on irregular surfaces.
Comprehensive correction options including horizontal & vertical keystone, hexagonal correction, pincushion, barrel distortion correction, and multi-point keystone correction for optimal imaging on irregular surfaces.
With 12,000 lumens output, the MX-X12000U delivers vivid and sharp projection in all lighting conditions, making it ideal for boardrooms, lecture theaters, galleries, simulation experience venues, and other large spaces.
Technical Specifications
| Model No. | MX-X12000U |
| Brightness | 12,000 ANSI Lumens |
| Light Source | Laser |
| Display Technology | 3LCD Liquid Crystal Display |
| Native Resolution | WUXGA (1920 x 1200) |
| Light Source Lifetime | 20,000 hours (Normal & ECO modes) |
| Throw Ratio | 1.46-2.95 (16:10) |
| Zoom Ratio | 2x |
| Contrast Ratio | 100,000:1 (Minimum) |
| Noise Level | Normal (90%): 35dB, ECO1 (75%): 32dB, ECO2 (45%): 32dB |
| Input Ports | VGA (x1), HDMI 1.4 (x2), USB-A (x1), USB-B (x1), RJ45 (x1), DVI-D (x1), HD BaseT (x1), Audio in (x1) |
| Output Ports | VGA (x1), HDMI 1.4 (x1), Audio out (x1) |
| Control Ports | RS232 (x1), RJ45 Control (x1), USB-B Upgrade (x1), Wired Remote (IN/OUT) |
| Keystone Correction | Vertical: ±30°, Horizontal: ±30°, plus advanced correction features |
| Dimensions | 600 x 218 x 503 mm (W x H x D) |
| Net Weight | ~25 kg |
