High Contrast 3LCD Ultra Short Throw Laser Projector Powerful With 120 Inch Screen
MOQ:
1pc
Delivery Time:
5-20days
Brand:
SMX
Product Description
SMX 5000 Lumen Ultra Short Throw Laser Projector WUXGA
The SMX MX-WPL500U is an ultra-short-throw projector with a throw ratio of 0.235, featuring 3LCD technology and a laser light source. It delivers 5,000 lumens with a high contrast ratio for exceptional image quality and vivid color performance in large spaces. Optimized for narrow spaces, including home theaters, classrooms, meeting rooms, and exhibitions.
Key Features:
- Laser Light Source with 20,000-30,000 hours of lifespan
- 5,000,000:1 High Contrast Ratio
- 360 Degree Projection Capability
- Advanced Geometry Correction
- Compatible with UST ALR Screens
Space-Saving Design
The MX-WPL500U ultra short-throw projector can display large images from just centimeters away from the screen, making it ideal for environments with limited space, such as small meeting rooms, classrooms, bedrooms, and audiovisual rooms.
High Brightness & Vivid Images
With 5,000 lumen brightness, the MX-WPL500U delivers clear, vibrant images even in well-lit environments, perfect for presentations and events requiring projection in bright spaces.
Excellent Audio-Visual Performance
Features comprehensive connectivity, including HDMI, VGA, and USB ports. The built-in 16W speaker and audio output ensure high-quality sound to complement the stunning visuals.
Low Noise Operation
The closed internal circulation design maintains quiet operation at just 27dB in ECO mode, preserving audio clarity and creating a peaceful viewing environment.
Centralized Control for Efficient Management
Compatible with Crestron RoomView, PJ Link, and AMX Discovery for centralized device management, enhancing operational efficiency.
Advanced Keystone Correction
WUXGA Resolution Performance
Technical Specifications
| Model Information | |
|---|---|
| Model No. | MX-WPL500U |
| Brightness | |
| Lumen | 5000 |
| Display Specifications | |
| Panel | 3x0.63" with MLA |
| Display Technology | Liquid Crystal Display |
| Native Resolution | WUXGA (1920x1200) |
| Light Source | |
| Lifetime (Normal mode) | 20,000 hours |
| Lifetime (ECO2 mode) | 30,000 hours |
| Projection Lens | |
| F | F1.7 |
| f | 2.94mm |
| Lens Vendor | RICOH |
| Zoom/Focus | Manual |
| Throw Ratio | 0.235:1 |
| Screen size | 80-120" |
| Image Quality | |
| Contrast Ratio | 5,000,000:1 |
| Aspect Ratio | Native: 16:10 Compatible: 4:3/16:9 |
| Connectivity | |
| Input | VGA*1, HDMI*2, USB-A*, USB-B*1 (Display), RJ45*1 (Display), Audio in*1 |
| Output | VGA*1, Audio out*1 |
| Control | RS232*1, RJ45*1, USB-B *1 |
| Audio | |
| Speaker | 16W*1 |
| Adjustment Features | |
| Keystone Correction | V: ±5° H:±5° Pincushion/Barrel Correction 6 Corner Geometry correction Grid image tune |
| Network Control | |
| LAN Control (Crestron RoomView) | Yes |
| LAN Control (AMX Discovery) | Yes |
| LAN Control (PJ Link) | Yes |
| Supported Resolutions | |
| Computer Signal Input | VGA, SVGA, XGA, SXGA, WXGA, UXGA, WUXGA, 4K@30Hz |
| Video Signal Input | 480i, 480p, 576i, 576p, 720p, 1080i, 1080p |
| Special Features | |
| 360° projection | Yes |
| Physical Dimensions | |
| Product Size (WxHxD mm) | 520x435x168 |
| Net Weight (KG) | 11 |
| Accessories | |
| Manual Languages | Chinese, English |
| Standard Accessories | Power cord, Remote control |
