5600 Lumens WXGA Resolution 3LCD Projector with Installation Flexibility
Price:
750usd/pc
MOQ:
1pc
Delivery Time:
5-20days
Brand:
SMX
Product Description
HDMI 5600 Lumens High Brightness Projector
3LCD Standard Throw Projector 5600 Lumens WXGA Resolution
Key Features
- Brightness of 5600 Lumens
- WXGA (1280 x 800) Native Resolution
- 1.4 to 2.26 Throw Ratio
- 16:10 / 4:3 Aspect Ratios
- Contrast: 10000:1
- Lens Shift: ±45% Vertical / ±10% Horizontal
3x Higher Color Brightness and reliable performance - 3LCD, 3-chip technology
5,600 lumens Color Brightness for accurate, vivid color
WXGA Resolution
1280 x 800 HD widescreen resolution with a bright and colorful display that features 5600 lumens of color brightness (color light output) and 5600 lumens of white brightness (white light output). The lens shift is equipped with horizontal and vertical lens shifts.
HDMI Connectivity
It features an all-digital, HDMI audio and video connection, designed for HD quality with just one cable. HDBaseT combines HDMI, Ethernet, and RS-232 into one cable.
Installation Flexibility
Up to ±45 percent vertical and ±10 percent horizontal lens shift for precise positioning and alignment.
Specifications
| Model No. | MX-L5600W |
| Specifications | |
| Projection System | 3LCD, 3-chip technology |
| Brightness (Lumens) | 5600 |
| Native Resolution | WXGA (1280 x 800) |
| Aspect Ratio | 16:10 (Standard)/4:3 (Compatible) |
| Lamp Type | USHIO 280W |
| Lamp Life (H) | 3000H (Normal) / 4000H (ECO) |
| Contrast Ratio (Min) | 10000:1 |
| Keystone Correction | V: ±30° / H: ±15° Pincushion/Barrel/Corner |
| Projection Lens | |
| Zoom/Focus | Manual |
| Throw Ratio | 70"@2.1m; 1.4~2.26 : 1 |
| F-number | F 1.65~2.25 |
| Focal Length | f= 18.20~29.38mm |
| Zoom Ratio | 1.6x optics |
| Screen Size | 1.194m~14.81m (40''~300") |
| Lens Shift V | ±45% (Manual) |
| Lens Shift H | ±10% (Manual) |
| Interfaces | |
| VGA in | *2 |
| Audio in | *1 |
| YCbCr/Component | *1 (share with VGA in 1) |
| Video | *1 |
| Audio in (L/R)--RCA | *2 |
| S-Video | *1 (share with VGA in1) |
| HDMI | *2 (One is Compatible with MHL) |
| USB-A | *1 (Memory viewer) / WiFi Dongle (optional) |
| USB-B | *1 (Display) |
| RJ45 | *1 (Display) |
| VGA out | *1 (Share with VGA IN 2) |
| Audio out | *1 |
| RS232 | *1 |
| RJ45 | *1 (Control) |
| Others | |
| Speaker | 1x10W |
| Power Supply Voltage | 100~240V@ 50/60Hz |
| LAN control-RoomView (crestron) | Yes |
| LAN control-AMX Discovery | Yes |
| LAN control-PJ Link | Yes |
| Computer Signal Input | VGA, SVGA, XGA, SXGA, WXGA, UXGA, WUXGA, Mac |
| Video Signal Input | 480i, 480p, 576i, 576p, 720p, 1080p and 1080i |
| Dimension & Weight | |
| Projector Dimension (WxHxD mm) | 395x318x128 |
| Net Weight (KG) | 4.45 |
| Standard Accessory | |
| Standard Accessories | Power cord, VGA cable, Remote control, Manual |
Product Images
Len Shift
