Classic Brazilian 4 Stroke Off Road Bikes Adventure Motorcycle With 150cc Engine
Price:
Negotiable
MOQ:
40HQ
Delivery Time:
45 work days
Brand:
OEM
Product Description
Classic Brazilian Off-road With 150cc Single Cylinder Air-cooled Engine
Product Description
| ENGINE: | CG150 | ENGINE TYPE | SINGLE CYLINDER, AIR-COOLED, FOUR-STROKE |
|---|---|---|---|
| DISPLACEMENT: | 149CC | MAX. POWER: | 8.5/8500KW/R/MIN |
| MAX. TORQUE: | 10/6500N.M./RPM | IGNITION TYPE: | CDI |
| START SYSTEM: | ELECTRICAL/KICK | TRANSMISSION: | CHAIN DRIVE |
| MAX. SPEED: | 90KM/H | BRAKE: | FRONT DISC AND REAR DRUM |
- Brazilian off-road generation with CG150CC engine
- Youli Keihin carburetor and maintenance-free battery
- Straight front shock absorber with single rear shock absorber without bracket
- Ordinary instrument with front and rear mesh wheels
- Deep-tooth tires (front 90/100-19, rear 110/100-17)
- Reinforced square tube flat fork
- High-temperature painted muffler
- Front disc brake and rear drum brake
- Aluminum alloy rear handrail
Technical Specifications
| Dimensions (Length × Width × Height) | 2060×860×1180mm |
|---|---|
| Seat Height | 860mm |
| Wheelbase | 1350mm |
| Minimum Ground Clearance | 280mm |
| Maximum Load | 150kg |
| Steering Angle | 40° |
| Side Stand Tilt Angle | 13° |
| Ride Capacity | 2 Person |
| Dry Weight | 115kg |
| Fuel Tank Capacity | 11.5L |
| Front Tire Size | 90/100/21 |
| Rear Tire Size | 110/90/18 |
| Battery Size | 12V/6.5Ah |
| Bore × Stroke | 62×53 |
| Compression Ratio | 9.0:1 |
| Start-up Acceleration | 14S |
| Overtaking Acceleration | 13S |
| Lubrication Method | Pressure, Splash |
| Oil Volume | 1.1L |
| Clutch Type | Multi-plate wet clutch, manual |
| Spark Plug | A8RTC |
| Final Gear Ratio | 15:43 |
Product Images
Frequently Asked Questions
Q1. About us:
Jiangmen Songfeng Import and Export Co., Ltd. is the export arm of our manufacturing facility, Yuanhua Technology Co., Ltd. We provide factory-direct pricing and strict quality control, ensuring you receive competitive products straight from the source.
Q2. Payment Terms:
We require 30% deposit to begin production preparation, with the remaining 70% due upon completion before loading.
Q3. Delivery Timeline:
Depending on the order quantity, usually around 45 working days.
Q4. Customization:
We can meet OEM requirements and, with the customer's authorization, use the customer's brand. Displacement and other configurations can be modified upon request.
Q5. Packaging Parameters:
The size of SKD is 1830×460×840mm, and a 40HQ container can hold 96 units.
The size of CKD is 1400×760×380mm, and a 40HQ container can hold 147 units.
Q6. Minimum Order Quantity:
We usually recommend MOQ a 40HQ, which can be mixed with different complete motorcycles and spare parts. For the first order of small quantity, a quantity of 20GP is also acceptable. Appreciate your understanding that we do not handle retail exports.
Q7. After-sales Service:
We provide 24-hour online support to resolve quality issues at any time and guarantee the supply of all original spare parts to ensure your worry-free after-sales experience.
