Processing and Customization of Bending Head and Half Head of H62 Copper Tube of 304 Stainless Steel Pet Drinking Pipe
Processing and Customization of Bending Head and Half Head of H62 Copper Tube of 304 Stainless Steel Pet Drinking Pipe
Product Name:
Custom Processing of 304 Stainless Steel Tube, H62 Brass Tube, and 6061 Aluminum Tube for Pet Water Pipes and Sensor Housings (End Capping, Bending, Sandblasting & Anodizing)
Product Application:
These custom-processed metal tubes are designed for durable and functional components in pet care products and electronic sensor assemblies. The specific materials are selected to meet distinct requirements for corrosion resistance, machinability, and electrical/thermal conductivity.
-
Pet Care & Hydration Systems: Durable, non-toxic water pipes and connectors for automatic pet water fountains, drinking nozzles, and pet feeder systems.
-
Electronics & Sensor Housings: Protective enclosures for environmental sensors, waterproof housings for electronic controls, and structural frames for IoT devices.
-
Industrial & Consumer Goods: General-purpose structural tubing, custom fluid conduits, and lightweight mechanical components.
Product Description:
We provide comprehensive custom fabrication services for 304 stainless steel, H62 brass, and 6061 aluminum tubes, tailored specifically for components like pet water pipes and sensor housings. Our process begins with precision tube cutting, followed by end forming—including full end capping for sealed terminals and partial end closing for specific functional openings. We then perform precision bending to achieve the required 2D or 3D shapes. For finishing, sandblasting is applied to achieve a uniform matte texture, and anodizing (for aluminum parts) is available to enhance surface hardness, corrosion resistance, and aesthetic appearance. Each material is selected for its unique properties: 304 stainless steel for strength and rust resistance in wet environments, H62 brass for excellent machinability and anti-microbial properties, and 6061 aluminum for its lightweight strength and anodization capability.
Product Technical Parameters:
| Category | Parameter | Details / Specification |
|---|---|---|
| Base Materials | Material Options | 304 Stainless Steel: Excellent corrosion resistance, high strength. H62 Brass: Good machinability, natural anti-microbial, decent corrosion resistance. 6061 Aluminum: Lightweight, good strength-to-weight ratio, excellent anodization response. |
| Standard Forms | Seamless or welded precision tubing. | |
| Fabrication Processes | End Capping (封圆头 / 半封头) | Full Closure: Hermetic sealing of tube end. Partial Closure: Forming a reduced opening or specific terminal shape. Methods include crimping, spinning, or welding. |
| Bending (折弯) | CNC precision bending. Minimum bend radius dependent on material and tube diameter (typically 1.5x OD). No collapse or wrinkling. | |
| Surface Finishing | Sandblasting: Uniform matte finish (various grits available). Anodizing (Aluminum only): Clear, black, or colored anodic oxidation. Thickness: 5-25μm. |
|
| General Specifications | Outer Diameter (OD) Range | 2.0 mm to 25 mm (customizable beyond this range). |
| Wall Thickness Range | 0.3 mm to 2.0 mm. | |
| Tube Length | Custom cut to specified dimensions. | |
| Bend Angle & Accuracy | Angle tolerance: ±0.5° to ±1.5°. | |
| End-Use Specific | Pet Water Pipes | Emphasis on food-safe/material safety, smooth internal finish for easy cleaning, and robust external finish. |
| Sensor Housings | Emphasis on dimensional precision for component fit, EMI shielding capability (brass/steel), and environmental sealing. | |
| Quality & Compliance | Surface Cleanliness | Free of oils and processing debris. Clean-room packaging optional. |
| For Aluminum Parts | Anodizing per MIL-A-8625 Type II/III standards available. | |
| Documentation | Material certifications and inspection reports provided. |
