32 Inch IP65 Waterproof Portable Advertising Display With 60Hz And 5ms Response Time
Price:
780
MOQ:
1
Delivery Time:
7 working days
Brand:
YOULESHI
Product Description
32 Inch IP65 Waterproof & Lightweight Outdoor Portable LCD Display 4K Battery-Powered Sunlight-Readable
IP65 waterproof for rain/dust protection with lightweight (≤6kg) design for easy portability. Features 4K resolution with 1800-nit brightness for sunlight-readable performance, enabling cord-free outdoor use.
Structural Performance
- All-galvanized steel plate shell with imported metal paint finish, featuring anti-magnetic, anti-static, and waterproof properties. IP65-rated for all-weather outdoor waterproofing, dustproofing, anti-theft, and explosion-proof design.
- Comprehensive electrical protection including leakage, overload, overvoltage protection, lightning protection devices, and overheating protection.
- Dual-channel stereo surround power amplifier system with 8 ohms 2×10W output power.
- Designed for extreme environments (-50°C to +110°C) with stable air cooling structure and aluminum heat dissipation base plate.
- 6mm AR tempered laminated glass display surface.
- Modular design principle for all systems, ensuring sustainability and maintainability.
- Advanced light sensing system automatically adjusts ambient brightness to prevent glare while maintaining clear image display under direct sunlight.
Product Superiority
- High brightness LED backlight LCD screen with up to 1800nits brightness for clear visibility in sunlight.
- Unique liquid crystal substrate operates in wide temperature range (-50°C to 110°C) with fast startup and clear image display in low temperatures.
- True bright and vivid colors with resolution up to 2160 x 3840.
- Outdoor rainproof and heat-resistant metal shell designed for storm environments.
- Built-in single machine (network) playback board with optional industrial control computer and interactive multi-touch functionality.
Technical Specifications
| Panel Specifications | ||
|---|---|---|
| Panel type | 32"LED Panel | |
| Display size | 392.2×697.8mm(W*H) | |
| Display ratio | 16:9 | |
| Backlight type | Patented LED backlight modular components + constant current source drive components | |
| Resolution | 1080*1920/2160*3840 | |
| Display colors | 16.7M | |
| Luminance | 1800cd/m² / 2500cd/m² (sunlight-readable) | |
| Contrast ratio | 3500:1 | |
| Viewing angle | 178°(H) / 178°(V) | |
| Response time | 5ms | |
| Color system | PAL/NTSC/SECAM | |
| Lifespan | 60,000 hours | |
| Host Specifications | ||
| CPU | Cortex-A7 architecture, 1.5G main frequency | |
| Internal storage | 1G/2G/4G | |
| Built-in memory | 32GB/64GB/128GB | |
| Decoding resolution | Supports up to 1080P | |
| Operating system | Android 10.0 | |
| Network support | Ethernet, WiFi, 4G (optional) | |
| Video playback | Supports over 30 formats including AVI, rm, rmvb, MKV, WMV, MOV, MP4, DAT, VOB, PMP, MPEG, MPG, FLV, ASF, TS, TP, 3GP | |
| Picture format | Supports BMP, JPEG, PNG, GIF | |
| USB2.0 interface | 2 USB HOST standard interface, 2 USB extension interface | |
| System upgrade | Support USB upgrade, SD card upgrade, remote upgrade | |
| Battery Specifications | ||
| Battery technology | Blade battery, long service time, stable performance | |
| Charging interval | 7 hours | |
| Operating time | 14 hours | |
| Battery capacity | 50000 mAh | |
| Input voltage | 24V | |
| Working Environment | ||
| Working temperature | -50℃～110℃ | |
| Storage temperature | -45℃～80℃ | |
| Working humidity | 10%～90% | |
| Storage humidity | 10%～90% | |
| Power input | AC100V～240V | |
| Power consumption | ≤85W | |
| Standby power consumption | ≤3W | |
| Appearance color | Silver, grey, white, black, red | |
| Shell material | Galvanized steel plate + outdoor special baked paint | |
| Net weight | 36Kg | |
| Gross weight | 39Kg | |
| Wooden crate packaging weight | 56Kg | |
| Product size | 990.8*140*448.2mm | |
| Packing measurement | 1100*290*600mm | |
| Wooden box packaging size | 1050*200*660mm | |
Frequently Asked Questions
Q: Are you a factory or a trading company? What is the minimum order quantity?
A: We are a factory direct sales company. We have some stock available, and you can place an order for 1 unit for testing purposes.
Q: Where are your products used?
A: Our products are widely used in hospitals, schools, offices, conference rooms, shopping malls, airports, high-speed rail stations, parks, scenic areas, banks, office buildings, government halls, etc.
Q: What are the main products you manufacture?
A: We specialize in manufacturing display products including Indoor/Outdoor Digital Signage, Touch Information Screens, Conference/Teaching Interactive Tablets, LCD Video Walls, Industrial LCD Displays, Bar Screens, LCD Transparent Display Cabinet, OLED Transparent Screens, Portable Display Screen, LED Displays, LED Poster Screen, LED Transparent Screen, Holographic 3D Displays, 360 Degree Photo Booths, Live Streaming All-In-One Machines, AI Human Recognition Displays, Curved Displays, and Customized Designs.
Q: What is the delivery time? Where do you ship from?
A: Small orders typically ship within 5-7 days, while production time for orders of 10 units or more is around 15 days. Our factory is located in Guangming District, Shenzhen. We can arrange shipment to your freight forwarder in Shenzhen.
Q: Do you provide OEM and ODM services?
A: Yes, we offer OEM and ODM services including software customization, packaging design, and product labeling. Please consult our customer service for details.
Q: What is the warranty period for your products?
A: Our products come with a standard 1-year warranty and professional after-sales support. Contact our customer service for specific details.
Q: How do you ensure product quality?
A: All products undergo strict QC inspections during production. Export products complete a 72-hour aging test to ensure problem-free operation before shipment.
Q: How do you arrange transportation?
A: For samples, we recommend express (7-10 days) or air freight (10-15 days). Bulk orders are best shipped by sea for cost efficiency. Contact our customer service for details.
