Atex Certified Differential Pressure Level Transmitter 4mA-20mADC For Hazardous Area
Atex-Certified Differential Pressure Transmitter - For Hazardous Area Differential Pressure Monitoring
FD3051 series intelligent capacitive pressure transmitter is a high-precision,high stability,multi-parameter differential pressure measurement product,with HART protocol. The reliable explosion-proof structure design and standardized signal output, high accuracy and wide range, suitable for precision measurement of fluid pressure. Performing digital communication with HART375 Communicator, and electromagnetic radiation meets the IEC801 standard.
- The sensor adopts digital compensation and nonlinear correction.
- Enables convenient customized services.
- Maximum adjustable range ratio of 100:1.
- Wide range coverage, capable of measuring liquid level, density, pressure, differential pressure and flow rate in fluids.
- IP65 protection design, suitable for harsh on-site environments such as fields and open-air areas.
- Maximum accuracy up to 0.075% F.S (Full Scale).
- Complies with the requirements of GB3836 standard and has obtained explosion-proof certification.
- Fiber laser marking, with exquisite and delicate appearance.
- Digital circuit design, allowing on-site zero reset via buttons.
| Range | 0-0.1kPa ～ 40MPa |
|---|---|
| Accuracy | ±0.075%FS, 0.1%FS, 0.2(0.25)%FS, 0.5%FS (at 25℃, full scale) |
| Output Signal | Two-wire system (4～20)mA with superimposed digital protocol (HART), RS485 protocol |
| Process Medium | Liquids, gases, or steam |
| Power Supply | (12～32)VDC (24VDC recommended) |
| Ambient Temperature | (-40～80)℃ |
| Stability | 0.1%URL/3 years |
- Pressure Difference Monitoring Between Pipeline Ends (For identifying filter clogging, pipeline resistance changes, etc.
- Stratified Fluid Interface Detection (Locate oil-water, liquid-gas interfaces using differential pressure caused by density differences of different fluids)
- Drainage and Venting Control of Pressure Chambers (Coordinate with relief valves via differential pressure monitoring to discharge gas in liquids or accumulated liquid in gases)
Q: How soon can you arrange your production?
A: Once getting your product confirmation and receiving the prepayment, the production will be started immediately.
Q: How long is the delivery time for the product?
A: We will provide a specific delivery time based on your order quantity. For orders of 1 to 30 pcs, the delivery time is approximately 2 to 7 working days.
Q: How do you control your quality ?
A: Full inspection process (Incoming Material Screening, Process Control, and Performance Verification) to ensure quality + good warranty service(1 year free to change a new one without any human damage factors).
Q: What certificates do you have ?
A: We hold 6 invention patents, possess certifications for CE, ATEX, and SIL, and are a member of the HART Protocol. And before the delievry of goods, quality and safety inspection certification issued by third parts also can be offered.
Q: What's your warranty terms?
A: We offer 12 months warranty time.
Q: Can you provide ODM/OEM & Customized service?
A: Yes, OEM and ODM are both available, we have the professional R&D dept which can provide professional solutions for you.
