10kW/12kW Split-Phase Hybrid Solar Inverter – 48-500M Series for US Home & Commercial Backup

10kW/12kW Split-Phase Hybrid Solar Inverter – 48-500M Series for US Home & Commercial Backup

Dual MPPT | 120V/240V Output | OLED Touch Screen | UL 1741 | Parallel up to 60 Units

Product Introduction

The 48-500M Series Split-Phase Hybrid Solar Inverter is a next-generation energy solution featuring a brand-new exterior design and advanced hardware topology. Built with dual-channel MPPT, an OLED light-touch screen, and split-phase dual output, this inverter delivers reliable, efficient power for North American homes and small commercial applications.

With models ranging from 10kW to 12kW (split-phase), this series supports parallel connection up to 60 units, making it ideal for scalable residential and commercial energy storage systems. Whether you're building an off-grid system, a backup power solution, or a solar-plus-storage setup, the 48-500M Series delivers exceptional performance and durability.

Key Features

• Dual-Channel MPPT – Two independent MPPT trackers for maximum solar harvest.

• Split-Phase Dual Output – 120V/240V output for North American standard wiring.

• 10kW / 12kW Models – Choose the power level that suits your needs.

• OLED Light-Touch Screen – High-definition display with accurate, responsive touch control.

• High Efficiency – Max. efficiency >95% (mains mode) and >91% (inverter mode).

• Parallel Capable – Supports up to 60 units in parallel for large-scale systems.

• Pure Sine Wave Output – Clean power safe for sensitive electronics.

• Fast Transfer Time – 10ms typical bypass-to-inverter switching.

• Flexible Monitor Mode – Multiple monitoring options via USB/RS485/WiFi/GPRS.

• Max. Hybrid Charging – Up to 220A combined PV + AC charging current.

• Comprehensive Protection – Overload, overvoltage, undervoltage, short circuit, and temperature protection.

• Extreme Security – UL 1741 certified, FCC Part 15 Class B compliant.

• Excellent Heat Dissipation – Forced air cooling with variable-speed fan.

• Durable Design – Conformal coating protection for harsh environments.

Part 2 – Key Specifications (Table)

Part 3 – Details & Convenience

Advanced Design. Intuitive Control. Built to Last.

The 48-500M Series is engineered for performance, reliability, and ease of use:

• OLED Light-Touch Screen – High-definition display with accurate, responsive touch control for intuitive operation.

• Split-Phase Dual Output – 120V/240V output supports both standard US household appliances and larger loads.

• Dual-Channel MPPT – Two independent MPPT trackers maximize solar harvest even with panels facing different orientations.

• Parallel Capable – Scale your system up to 60 units for large-scale residential or commercial installations.

• Flexible Monitoring – Multiple communication options: USB, RS485, WiFi, GPRS, and dry contact.

• Max. Hybrid Charging – Combine PV and AC charging for up to 220A total charging current.

• Power-Saving Mode – Automatically enters power-saving mode when load ≤25W.

• Excellent Heat Dissipation – Forced air cooling with variable-speed fan ensures reliable operation under heavy loads.

• Conformal Coating Protection – Built to withstand harsh environmental conditions.

• Loaded Motor Capability – Supports motors up to 5HP (10kW model) or 6HP (12kW model).

Safety First

• UL 1741 Certified – Meets North American safety standards.

• FCC Part 15 Class B – Compliant with EMC requirements.

• Comprehensive Protection – Overload, overvoltage, undervoltage, short circuit, and temperature protection.

• Extreme Security – Designed for safe, reliable operation in demanding environments.

Part 4 – Application Scenarios

Where Can You Use It?

???? Home Energy Storage
Power your entire home with 10kW or 12kW split-phase output. Run air conditioners, refrigerators, lights, TVs, and more — all from a single inverter.

???? Backup Power During Outages
With a fast 10ms transfer time, the inverter automatically switches to battery mode when the grid fails, keeping essential appliances running seamlessly.

???? Small Business & Offices
Keep computers, POS systems, security cameras, and lighting operational during power cuts. Ensure business continuity with reliable backup power.

???? Off-Grid & Remote Sites
Ideal for farms, remote cabins, and off-grid homes where grid access is limited or unavailable. Dual MPPT ensures maximum solar harvest.

⚡ Solar-Plus-Storage Expansion
Already have solar panels? This inverter integrates seamlessly with existing PV setups, adding battery storage and grid backup capabilities.

???? Parallel Systems for Large Installations
Supporting up to 60 units in parallel, this inverter is perfect for large residential communities, commercial buildings, and microgrid projects.
