High Security Anti Climb Steel Palisade Fencing Q345 Steel For Airports Prisons
High-Security Anti-Climb Steel Palisade Fence Q345 Steel for Airports Prisons
Product Description:
Our High-Security Anti-Climb Steel Palisade Fence is engineered for high-risk perimeter protection (airports, prisons, military bases). Unlike ordinary palisade fences, it adopts Q345 high-strength steel (30% stronger than Q235) with sharpened pickets (15° tip angle) to prevent climbing, and anti-shear lock connections to resist forced entry. The 120μm hot-dip galvanized surface ensures 15+ years of anti-rust performance in outdoor harsh environments, reducing maintenance costs for high-security facilities.
Specification & Selection Table:
|
Model
|
Height
|
Picket Thickness
|
Rail Thickness
|
Post Thickness
|
Anti-Impact
|
Applicable Scene
|
|
SP-H180
|
1.8m
|
3.0mm
|
3.5mm
|
4.0mm
|
≥1000kg
|
Industrial Park Perimeter
|
|
SP-H240
|
2.4m
|
3.0mm
|
3.5mm
|
4.5mm
|
≥1200kg
|
Airport Security Zone
|
|
SP-H300
|
3.0m
|
3.5mm
|
4.0mm
|
5.0mm
|
≥1500kg
|
Prison/Military Base
|
Characteristics:
Anti-Climb Design: Sharpened picket tips (15° angle) + 100mm picket spacing (prevents foot placement)
High Strength: Q345 steel resists deformation under 1200kg impact (no bending or breaking)
Anti-Shear Connection: Locked rail-post joints resist 16mm bolt cutter cutting (forced entry proof)
Long Durability: 120μm galvanization + passivation (500-hour salt spray test no rust)
Security Compatibility: Pre-drilled holes for surveillance cameras/sensor installation
Advantages:
High-Security Compliance: Meets airport/military perimeter standards (e.g., IATA airport security requirements)
Low Maintenance: No repainting needed (15-year anti-rust life vs. 8-year ordinary fence)
Fast Installation: Modular panels (2.4m/3.0m) + pre-welded brackets (1 worker installs 40m/day)
Custom Height: 1.8m-3.0m to match different security levels (e.g., 3.0m for prisons)
Global Certification: CE/ASTM compliance
Technology:
Material Science: Q345 steel undergoes quenching + tempering to achieve 345MPa yield strength; picket tips are precision-ground to 15° using CNC machining
Locking Mechanism: Patented 3-point lock design (horizontal, vertical, and rotational locking) distributes shear force across 3 load paths
Coating Technology: Dual-layer protection—150μm hot-dip galvanization (ASTM A123) followed by chromate passivation (ASTM B633) for enhanced adhesion
Application:
Aviation Security: Perimeter fencing for international airports (e.g., Dubai International Airport’s 2.4m SP-H240 installation with integrated CCTV)
Correctional Facilities: Maximum-security prisons (e.g., UK’s HMP Belmarsh using 3.0m SP-H300 with anti-drone netting integration)
Critical Infrastructure: Nuclear power plants (e.g., France’s EDF Flamanville using 3.5m SP-H350 with seismic-resistant posts)
Military Zones: NATO bases in Germany using 3.0m SP-H300 with camouflage powder coating (RAL 6031)
Industrial Complexes: Petrochemical plants in Singapore using 1.8m SP-H180 for hazardous area perimeter
