Customizable Steel Metal Palisade Fencing For Commercial Parks Residential Areas
Customizable Steel Palisade Fence for Commercial Parks Residential Areas
Product Description:
Specification & Selection Table:
|
Model
|
Height
|
Material
|
Picket Thickness
|
Color Option
|
Load Capacity
|
Application Scenario
|
|
SP-C080
|
0.8m
|
Q235
|
2.0mm
|
Green
|
≥500kg
|
Residential Garden Boundary
|
|
SP-C120
|
1.2m
|
Q235
|
2.0mm
|
Gray
|
≥600kg
|
Commercial Plaza Flower Bed Fence
|
|
SP-C180
|
1.8m
|
Q345
|
2.5mm
|
Black
|
≥800kg
|
Office Park Perimeter
|
|
SP-C200
|
2.0m
|
Q345
|
3.0mm
|
Custom Color
|
≥1000kg
|
Municipal Greenway Protection
|
Characteristics:
Safety-First Design: Rounded picket tops (radius ≥5mm) eliminate sharp edges—certified safe for residential areas with children/pets
Aesthetic Customization: 200+ RAL powder coating colors (ΔE ≤1 color accuracy) + optional decorative spacers (floral/geometric patterns)
Weather Resistance: Dual-layer protection (galvanization + powder coating) resists rain, UV rays, and urban pollution—1000h UV test no fading
Modular Flexibility: 1.8m/2.4m panels allow easy on-site adjustment; single panels can be replaced without dismantling the entire fence
Advantages:
Landscape Integration: Color-matching service (sample swatches provided) ensures fence aligns with building exteriors or garden designs
Cost-Effective: Q235 models 30% cheaper than high-security fences; 12-year service life reduces replacement frequency
Fast Installation: Lightweight panels (8-12kg/m) + pre-assembled brackets; 2 workers install 100m/day (faster than wooden fences)
Low Maintenance: Smooth powder coating resists dirt accumulation—only needs annual cleaning with water; no repainting required
Production Process
Material Preparation: Q235/Q345 steel coils → CNC cutting (pickets/rails/posts, tolerance ±0.5mm)
Forming: Pickets—hydraulic pressing for rounded tops; Rails—roll forming; Posts—extrusion with pre-drilled holes
Surface Treatment: Degreasing → pickling → hot-dip galvanization (85-110μm) → curing → powder coating (80μm, RAL color matching)
Assembly: Modular panel assembly (pickets + rails) → decorative spacer installation (if customized)
Quality Control: Color accuracy test (ΔE ≤1) → UV resistance test (1000h) → load test (≥800kg) → edge safety check
Packaging: Individual panel wrapping (PE film) + cardboard separators (prevents color scratching) + wooden pallets
FAQ:
Q1: Can the color match my office building’s exterior?
A1: Yes—send us a paint sample or RAL code, and we’ll provide a color swatch for confirmation (no extra cost).
Q2: Is the fence safe for my residential community with kids?
A2: Absolutely—rounded picket tops (radius ≥5mm) and smooth edges meet child safety standards.
Q3: How long does the powder coating last outdoors?
A3: actual service life is 8-10 years in urban environments.
Q4: Can I install the fence myself (small residential project)?
A4: Yes—we provide a detailed installation manual and video; basic tools (drill, level) are sufficient.
