Hot-Dip Galvanized Gabion Basket Wall Retaining Wall 2x1x1m River Floodplain Stone Revetment
To build a gabion structure, the mesh is cut, folded into boxes (or baskets), and laced together on site. Then stones are packed inside—usually 100–250 mm in diameter for standard baskets. The voids between stones allow water to drain freely, so no special drainage pipes are needed. Over time, silt and seeds accumulate in the gaps, and vegetation naturally takes root, making the structure stronger and more attractive.
Compared to concrete, woven gabion structures are cheaper, easier to repair, and more environmentally friendly. Compared to welded gabion mesh, the woven type offers better flexibility and resistance to breakage under uneven settlement.
- Material: Hot-dip galvanized steel (Zn ≥ 250g/m²), PVC-coated options (0.5mm thickness)
- Design: Hexagonal double-twist mesh, 90x110mm standard apertures (customizable)
- Coatings: Epoxy/Zinc-Aluminum alloy for marine/coastal applications
- Fillers: Crushed rock, recycled concrete, or vegetated soil (client-specified)
- 3x Lifespan: 50-100 years corrosion resistance
- Load Capacity: Up to 50kN/m² vertical pressure
- Eco-Friendly: 100% recyclable materials with zero chemical runoff
- Modular Assembly: Interlocking panels for 70% faster installation
- Civil Engineering: Riverbank stabilization, highway embankments
- Architecture: Retaining walls, sound barriers, decorative façades
- Disaster Prevention: Flood control barriers, landslide mitigation systems
- Mining: Tailings dam reinforcement, slope retention
- Sizes: 2x1x1m (standard) up to 6x2x1m (heavy-duty)
- Wire Diameters: 2.2mm - 4.0mm (3.0mm recommended for high-load zones)
- Colors: Metallic Silver (standard), Green/Black PVC coating (urban projects)
| Mesh hole model | ||||
|---|---|---|---|---|
| 8x10cm | 6x8cm | |||
| Length(m) | Width(m) | Height(m) | Galvanized or PVC coated | Galvanized or PVC coated |
| 2 | 1 | 1 | 2.7mm >245g/m² | 2.0mm >215g/m² |
| 3 | 1 | 1 | 3.4mm >265g/m² | 2.7mm >245g/m² |
| 4 | 1 | 1 | Binding wire diameter of 2.7m | |
| 6 | 1 | 1 | Binding wire diameter of 2.0m | |
