3600W Hybrid Solar Inverter With 120A MPPT Controller And 110v Pure Sine Wave Output
Price:
Negotiable
MOQ:
2
Delivery Time:
8-10work days
Brand:
shunxiang
Product Description
3600W/3600VA Hybrid Solar Inverter - Pure Sine Wave 110v/120v with 120A MPPT Charge Controller
Product Overview
This multi-function inverter/charger combines inverter, solar charger, and battery charger capabilities to provide uninterruptible power support in a portable size. The comprehensive LCD display offers user-configurable operation for battery charging current, AC/solar charger priority, and input voltage settings.
Key Features
- Pure sine wave inverter output
- Configurable input voltage range for appliances and computers via LCD
- Adjustable battery charging current based on application needs
- Configurable AC/solar charger priority via LCD
- Compatible with mains voltage or generator power
- Auto restart when AC power recovers
- Overload, over temperature, and short circuit protection
- Smart battery charger design for optimized performance
- Cold start function
System Architecture
The basic system requires a generator or utility connection along with PV modules. This inverter can power all types of home and office appliances, including motor-type devices like tube lights, fans, refrigerators, and air conditioners.
Control Panel Components
- LCD display
- Status indicator
- Charging indicator
- Fault indicator
- Function buttons
- Power on/off switch
- AC input
- Main output
- Second output
- Battery input
- PV input
- Antidust kit
- WIFI communication/RS-232 port
- Battery communication/RS-485 port
Technical Specifications
Line Mode Specifications
| INVERTER MODEL | 3.6KW | 4.2KW | 6.2KW |
|---|---|---|---|
| Input voltage waveform | Sinusoidal (utility or generator) | ||
| Nominal Input voltage | 230VAC | ||
| Low Loss voltage | 170VAC±7V (UPS); 90VAC±7V (Appliances) | ||
| Low Loss Return voltage | 180VAC±7V (UPS); 100VAC±7V (Appliances) | ||
| High Loss voltage | 280VAC±7V | ||
| High Loss Return voltage | 270VAC±7V | ||
| Max AC Input voltage | 300VAC | ||
| Nominal Input Frequency | 50HZ/60HZ (Auto detection) | ||
| Low Loss Frequency | 40±1HZ | ||
| Low Loss Return Frequency | 42±1HZ | ||
| High Loss Frequency | 65±1HZ | ||
| High Loss Return Frequency | 63±1HZ | ||
| Output short circuit protection | Circuit Breaker | ||
| Efficiency (Line Mode) | >95% (Rated R load, battery fully charged) | ||
| Transfer Time | 10ms typical (UPS); 20ms typical (Appliances) | ||
Inverter Mode Specifications
| INVERTER MODEL | 3.6KW | 4.2KW | 6.2KW |
|---|---|---|---|
| Rated output power | 3.6KW | 4.2KW | 6.2KW |
| Output voltage waveform | Pure sine wave | ||
| Output voltage Regulation | 230VAC±5% | ||
| Output Frequency | 50HZ | ||
| Peak Efficiency | 93% | ||
| Overload protection | 3s@≥150% load; 5s@100%-150% load | ||
| Surge capacity | 2× rated power for 5 seconds | ||
| Nominal DC Input voltage | 24VDC | 24VDC | 48VDC |
| Cold start voltage | 23.0VDC | 23.0VDC | 46.0VDC |
| Low DC warning voltage @ load < 50% | 22.0VDC | 22.0VDC | 44.0VDC |
| Low DC warning voltage @ load ≥ 50% | 21.0VDC | 21.0VDC | 42.0VDC |
| Low DC warning Return voltage @ load < 50% | 22.5VDC | 22.5VDC | 45.0VDC |
| Low DC warning Return voltage @ load ≥ 50% | 22.0VDC | 22.0VDC | 44.0VDC |
| Low DC cut-off voltage @ load < 50% | 20.5VDC | 20.5VDC | 41.0VDC |
| Low DC cut-off voltage @ load ≥ 50% | 20.0VDC | 20.0VDC | 40.0VDC |
| High DC Recovery voltage | 32VDC | 32VDC | 62VDC |
| High DC Cut-off voltage | 33VDC | 33VDC | 63VDC |
| No Load power consumption | 30W | 35W | 50W |
