5kW AC Output Residential Solar Battery Storage 10kWh With 3400W MPPT Charging
Price:
Negotiable
MOQ:
20
Delivery Time:
18-20work days
Brand:
shunxiang
Product Description
5kW AC Output 10kWh Capacity Portable Home Solar Energy Storage Power Supply
Product Specifications
| Rated Power | 5000W |
| AC Output | 5000W |
| Capacity | 10kWh |
| Cut-off Charging Voltage | 54.8V |
| Cut-off Discharging Voltage | 41.6V |
| Rated Charging Current | 50A (Maximum: 60A) |
| Output Voltage | 40-56Vdc |
| Rated Discharge Current | 100A (Maximum: 200A) |
| Interface | RS485 for LCD/CAN |
| Solar Charging Support | Built-in 3400W MPPT |
| Weight | 128kg |
Product Features
Control Panel and Ports
- Power Switch
- Status Indicator
- Exit
- Up
- Down
- Confirm
- Charging Indicator
- Fault Indicator
- PV- Input
- PV+ Input
- Battery Negative Terminal
- Battery Positive Terminal
- Battery Negative Terminal
- Battery Positive Terminal
- AC Output
- AC Output
- RS485
- AC Charging
- DIP Switch
- Reset Switch
- Low-voltage Switch
- ON/OFF Indicator
- RUN Indicator
- ALM Indicator
- SOC Indicator
- Dry Contact
- Communication RS485
- Communication CAN
- RS232
- Parallel RS485
- Parallel RS485
Operating Instructions
- Turn on Low-voltage Switch (21) to activate battery output.
- Turn on Power Switch (1) to activate inverter output.
- Status indicator (Green):
- ① In grid-tied mode, output is powered by utility grid and remains steady.
- ② In battery mode, output is powered by battery or PV and flashes.
- Charge Indicator (Green):
- ① Fully charged battery: Steady on
- ② Charging battery: Flashing
- Fault Indicator (Red):
- ① Inverter fault: Steady on
- ② Inverter warning: Flashing
- Function Keys:
- ① Exit: Leave setup mode
- ② Up: Return to previous selection
- ③ Down: Navigate to the next option
- ④ Confirm: Confirm selections in setup mode or enter setup mode
- Pressing the Up or Down keys cycles through LCD display messages
- Hold the Confirm key for 3 seconds to enter setup mode. Press the Up or Down keys to select a setup program. Press Confirm to confirm the selection or Exit to cancel.
