Vacuum Metallizing Coating Machine for Glass Products Laser Equipment Aluminum Painting Machine
|
configuration Model |
CCZK-1000EL |
CCZK-1200EL |
CCZK-1400EL |
CCZK-1800EL |
CCZK-2200EL |
Customized Size is available |
|
Chamber size(MM) |
D1000*H1200 |
D1200*H1500 |
D1400*H1800 |
D1800*H2000 |
D2200*H2400 |
Customized |
|
Vacuum system |
Diffusion pump/Molecular pump + Roots pump + Rotary pump + Holding pump + Cryogenic pump(optional) |
Customized |
||||
|
Evaporation power |
10KW |
15KW |
20KW |
30KW |
40KW |
Customized |
|
Evaporation source |
20sets |
26sets |
36sets |
52sets |
68sets |
Customized |
|
Ion glow cleaning system |
5KW |
5KW |
10KW |
15KW |
20KW |
Customized |
|
Control system |
PLC+HMI Full automatic + Remote control system ( optional) |
Customized |
||||
|
Ultimate vacuum |
5.0*10-4pa |
5.0*10-4pa |
5.0*10-4pa |
5.0*10-4pa |
5.0*10-4pa |
Customized |
|
Total power |
30.6KW |
37.5KW |
58.5KW |
96KW |
125KW |
Customized |
|
Coating Cycle time |
6 to 10mins one cycle ( Depending on the coating film layer of different coating products) |
Customized |
||||
|
Delivery container size |
1set 20GP |
1set 20GP |
1set 40GP |
1set 40HQ |
1set 40HQ |
Customized |
|
Machine installing time |
5days (1engineer) |
5days (1engineer) |
7days (1engineer) |
7days (2engineers) |
7days (2engineers) |
Customized |

A: Please provide a photo of the product you used before or advise us your needs, we will give suggestions.
A: The more you order, the more discount you will get.
A: 100% in advance. Payment>=50000USD, 50% T/T in advance, balance before shipment.
A: When the order is confirmed, 3-5 working days for the small order, 2-6 weeks for the bulk depending on the quantity and product type.
