Custom 3-12V Low Rpm DC Gear Motor High Torque With Flat Gearbox
Price:
Negotiable
MOQ:
1000 Pieces
Delivery Time:
15-30 days/Negotiable
Brand:
FUTENG
Product Description
Custom 3-12V High Torque Low Rpm DC Gear Motor With Flat Gearbox 1-35kg.Cm 5-5000rpm Gear Motor
FT MOTOR
FT MOTOR Geared motor model: FT-65FGM520 Gearbox diameter: Ø65*38mm Voltage: 3-24V Speed: 5rpm-2000rpm DC gear motors are widely used: Robots, electronic locks, public bicycle locks, ATM machines, electric glue guns, household appliances, 3D printing pens, electric toothbrushes, office equipment, massage health care, beauty and fitness equipment, medical equipment, toys, electric daily necessities, automotive automatic facilities, etc.
|
Gearbox Data:
|
|
|
|
|||
|
Gear stage
|
3
|
4
|
5
|
|||
|
Reduction ratio (K)
|
41.8,67.5
|
135,225
|
450
|
|||
|
Gear box length L(mm)
|
12
|
12
|
12
|
|||
|
Rated torque (kg·cm)
|
2
|
6
|
8
|
|||
|
Instant torque (kg·cm)
|
6
|
18
|
24
|
|||
|
Gearbox efficiency (%)
|
73%
|
65%
|
59%
|
|||
|
Motor Data
|
|
|
|
|
|
|
|
|
|
|||||||||
|
Motor Model
|
|
No Load
|
|
Load
|
|
|
|
Stall
|
|
|||||||||
|
Motor Model
|
Rated Voltage
|
Speed
|
Current
|
Speed
|
Current
|
Output
|
Torque
|
Current
|
Torque
|
|||||||||
|
|
V
|
(rpm)
|
(mA)
|
(rpm)
|
(mA)
|
(w)
|
(g·cm)
|
(mA)
|
(g·cm)
|
|||||||||
|
FT-520
|
6
|
3000
|
35
|
2600
|
130
|
0.78
|
15
|
500
|
100
|
|||||||||
|
FT-520
|
12
|
6000
|
60
|
5500
|
150
|
1.8
|
15
|
1000
|
135
|
|||||||||
|
FT-520
|
24
|
5500
|
30
|
4900
|
110
|
2.65
|
20
|
560
|
150
|
|||||||||
|
FT-520
|
24
|
7500
|
50
|
6700
|
120
|
2.9
|
15
|
900
|
230
|
|||||||||
