FT-37RGM3530 High Torque Geared DC Motor for Automatic Table

Price Negotiable

Price: Negotiable

MOQ: 1000 Pieces

Delivery Time: 15-30 days/Negotiable

Brand: FUTENG

Product Description

FT MOTOR

Geared motor model: FT-37RGM3530 Gearbox diameter: Ø37mm Voltage: 1-24V Speed: 1rpm-1500rpm DC gear motors are widely used: Robots, electronic locks, public bicycle locks, relays, electric glue guns, household appliances, 3D printing pens, electric toothbrushes, office equipment, massage and health care, beauty and fitness equipment, medical equipment, toys, electric daily necessities, curling irons, automatic car facilities, etc.

Gearbox Data:
Gear stages	2	3	4	5	6	7
Reduction ratio (K)	6.8,10	20,30	61,90,100	115,184 270,300	414,552,614 810,900	1243,1657 2430,2700
Gear box length L(mm)	18	21.5	24	26.5	29	31.5
Rated torque (kg·cm)	1	2	5	6	8	10
Instant torque (kg·cm)	3	6	15	18	24	30
Gearbox efficiency (%)	81%	73%	65%	59%	53%	48%

Motor Data
Motor Model		No Load			Load						Stall
	Motor Model	Rated Voltage	Speed	Current	Speed	Current	Output	Torque	Current	Torque
		V	(rpm)	(mA)	(rpm)	(mA)	(w)	(g·cm)	(mA)	(g·cm)
FT-3530	12	3000	60	2550	170	2.04	20	460	200
FT-3530	12	6000	70	4500	350	4.2	110	2300	440
FT-3530	24	4500	40	3300	150	3.6	50	700	270
FT-3530	24	6000	40	4500	200	4.8	100	1400	400
