PU Rtv Potting Compound Electronic Epoxy Encapsulant Potting Compounds 6800 BK
Excellent Electrical Properties | UL94-V0 Polyurethane Potting Compound
Product Description
BZ-6800 is a UL94-V0-rated polyurethane potting material (UL No.: QMFZ2.E352175), fully compliant with RoHS and REACH standards. It offers high structural strength, strong substrate adhesion, robust mechanical performance, and superior electrical characteristics. Widely used for potting in electronics and electrical equipment.
Key Product Features
- Low viscosity, adaptable to manual or automated dispensing;
- Broad operating temperature range;
- Stable, high-grade electrical insulation;
- UL94-V0 flame-retardant grade;
- Exceptional moisture and waterproof protection, with ultra-low water uptake;
- Strong bonding to common plastics and metals.
Technical Parameters
|
Parameters |
Hardener BZ-6800(BK) A |
Resin BZ-6800(BK)B |
|
|
Before curing |
Appearance |
Brown liquid |
Black liquid |
|
Viscosity(mPa·s.25℃) |
150±100 |
3750±1250 |
|
|
Initial mixed viscosity(mPa·s.25℃) |
1350±350 |
||
|
Density(g/cm³.25℃) |
1.15±0.05 |
1.52±0.05 |
|
|
Mixing&Curing
|
Mix ratio(by weight) |
A:B=(20~25):100 |
|
|
Pot life 130±30g(min.25℃) |
25±10 |
||
|
Curing condition |
Room temperature curing |
||
|
Surface drying time 30g(H.25℃) |
6-8.5 |
||
|
Curing time 30g(H.25℃) |
9-13 |
||
|
Curing time(Heated) |
60℃ heated 1-2H |
||
|
After curing
|
Color |
Black |
|
|
Hardness (Shore A) |
40-55 |
||
|
Temperature resistance(℃) |
-40~120℃ |
||
|
Flame retardancy UL94 (vertical burning) |
V-0(3mm) |
||
|
Water absorption(24H) |
≤0.5% |
||
|
Thermal conductivity(W/m.k) |
≥0.5 |
||
|
Surface resistivity(Ω/sq) |
≥1.0×1013 |
||
|
Volume resistivity(Ω.cm) |
≥1.0×1013 |
||
|
Tensile strength(MPa) |
≥3 |
||
|
Elongation at break(%) |
≥50% |
||
|
Dielectric constant(at 50Hz) |
≥6 |
||
|
Breakdown voltage(kV/mm) |
≥18 |
||
Product Applications
- Communication Equipment.
- Power Tools.
- Controllers.
- Modules.
- LED Power Supply.
Directions for Use
- Pre-potting Preparation: Calibrate scales, prepare potting tools, cleaning tools, check machine settings, check vacuum pump force, etc.
- Product Pre-treatment: Place product on a level surface or fixture. Remove dust, clean, degrease, and dry if necessary.
- Accurate Proportioning: Manual operation requires precise mixing according to the specified ratio and recording. Machine potting requires calibrated ratios and first-article confirmation is recommended.
- Mixing & Stirring: Manual operation requires thorough stirring or using electric stirrers to ensure homogeneous mixing. Machine potting requires sufficient stirring speed, adjust as needed.
- Uniform Potting: Manual operation should be done in small, multiple batches to ensure uniformity. Machine potting should follow the programmed path for quantitative dispensing.
- Inspection or Secondary Potting: After potting, visually inspect as needed. Perform touch-up, bubble removal, or secondary potting if required.
- Curing: Allow the potted and inspected products to cure at room temperature or with heat assistance (recommended 60°C if needed), according to product and process requirements.
- Final Product Confirmation: Perform visual inspection and performance testing as required by the customer.
Packing
- Hardener: Typically 5KG/10KG/25KG/200KG metal or plastic drums.
- Resin: Typically 25KG/200KG metal or plastic drums.
