25KW Portable Induction Brazing Machine Automatic 30KHZ-80KHZ

Price Negotiable
Price: negotiation
MOQ: 1 set
Delivery Time: 7~15days
Brand: InductionFusion
Product Description

25KW Automatic Portable Induction Brazing Machine Heating Use Diamond Tool

Our Machine adopts the IGBT inverter circuit in parallel connection,which has high load adaptability.It have such as high power,fast heating speed,high efficiency and easy operation.and repeatable heat treatment method for heating metals or other electrically-conductive material.Material is a metal such as steel,iron,brass,aluminum,alloy,copper,stainless steel,tungsten,nickel,precious metals,silver,zinc,gold and etc.or be semiconductor such as silicon carbide,carbon or graphite.

work power 340V-430V
input current 25A
Fluctuating output power 25KW
fluctuating frequency 30-80KHZ
output current 200-1200A
the flow rate of cooling water 0.06-0.12Mpa 7.5L/Min
water temperature protection point 40C
product size main 550x225x480mm
transformer : 350x215x380mm
net weight main : 21.5 kgs
transformer : 17 kgs




Induction Brazing Machine Main Application:



It mainly aims to melt the solder by heating it to a certain temperature for the purpose of connecting two types of metals of the same material or different materials.



1) Welding of various hardware cutting tools, such as diamond tool, abrasive tool, drilling tool, alloy saw blade, hard alloy cutter, milling cutter, reamer, planning tool and solid center bit.



2) Welding of various hardware mechanical gadget: Silver soldering and brazing of metals of the same variety or different varieties, such as hardware toilet and kitchen products, refrigerating copper fitting, lamp decoration fitting, precision mold fitting, hardware handle, eggbeater, alloy steel and steel, steel and copper as well as copper and copper.



3) Compound pot bottom welding is mainly applicable to the braze welding of circular, square as well as other irregular plain pot bottom. It is also applicable to plain braze welding of other metals.



4) Welding of heating disc of electric hot-water kettle mainly refers to the braze welding of stainless steel flat base, aluminum sheet and tubular electric heating elements of various forms.
