360V-520V Induction Melting Equipment 40KW Induction Heating Device
Induction Melting Equipment with 40KW Induction Heating device
Key attributes
| Work power | 360V-520V |
| Maximum input current | 65A |
| Output power | 40kw |
| Fluctuating frequency | 20-50khz |
| Output current | 400-1800A |
| The flow rate of cooling water | 0.08-0.16Mpa 9L/Min |
| Water temperature protection point | 50C |
| Product size | main : 690x600x1060mm |
| transformer : 570x290x470mm | |
| Net weight | main : 60kgs |
| transformer : 28kgs |
Major Features
-
CE Approved Induction Melting Equipment Ultrahigh Frequency Induction Heating 40KW adopts Soft-switch ultrahigh frequency technology and two poles closed loop control technology; and our company fully owns the independent intellectual property rights
-
Fluctuating frequency can be 100K-1.5MHZ, control the depth of surface quenching, which can totally replace the high frequency of vacuum tube.
-
CE Approved Induction Melting Equipment Ultrahigh Frequency Induction Heating 40KW can continuously work for 24 hours, and 100% duty cycle.
-
Parts of power devices are all from well-know brand products
-
Ultra-small size and weight; High efficiency, energy saving and environmental protection with safety.
Customization options
Customized logo (Min. order: 1 piece)
Customized packaging (Min. order: 1 piece)
Graphic customization (Min. order: 1 piece)
Q:How to choose suiteble machine?
A:You can tell us your application,need forging,hardening,welding,melting or other,pass me workpiece material & size,Temperature requirement and heating time requirement.Then we will recommend fit machine for you reference.
Q:How about the machine delivery time?
A: Small machine delivery time is 3~7 workdays.Big machine delivery time 15~25 workdays.
Q:How about the machine warranty?
A:Our goods support one year warranty not by personal purpose,support technical service all life.
During the warranty,if machine have problem need change spare parts,we can replace for you charge free.
