MTL5541S MTL Intrinsically Safe Barriers MTL5500 Repeater Power Supply
Price:
Negotiable
MOQ:
1
Delivery Time:
ship out immediately after payment received
Brand:
MTL
Product Description
Eaton Crouse-Hinds series MTL5500 repeater power supply, 1 channel, Analogue input, 24 Vdc max., 20-35 Vdc, 1.0W at 24 Vdc dissipation, 51mA at 24V, 4-20mA signal, HART (terminals 1 & 2 only), LED: Green = power, 2- or 3-wire transmitters
| Product Name |
Eaton Crouse-Hinds series MTL5500 repeater power supply
|
| Catalog Number |
MTL5541S - FSM ASSESSED
|
| EAN |
3066227675819
|
| Product Length/Depth |
109.8 mm
|
| Product Height |
118.8 mm
|
| Product Width |
15.8 mm
|
| Product Weight |
150 g
|
| Global Catalog |
MTL5541S
|
| Product Type |
Repeater power supply
|
| Type |
2- or 3-wire transmitters
|
| Area classification |
Hazardous/Classified Locations
|
| Standards type |
IEC
IECEx/ATEX |
| IECEx/ATEX hazardous rating |
Zone 0
|
| Minimum Ambient Operating Temperature |
-20 °C
|
| Maximum Ambient Operating Temperature |
60 °C
|
| Minimum Ambient Storage Temperature |
-40 °C
|
| Maximum Ambient Storage Temperature |
80 °C
|
| Humidity |
5-95% relative humidity
|
| Signal Type |
Analogue input
|
| Signal Range |
4-20mA
|
| Response Time |
Settles to within 10% of final value within 50µs
|
| Number of Channels |
1
|
| Terminal Capacity |
Accepts conductors of up to 2.5mm2 stranded or single-core
|
| Mounting Method |
T-section 35mm DIN rail
|
| EMC |
EN61326
|
| Ripple |
<50µA peak-to-peak
|
| Safety Integrity Level According to IEC61508 |
SIL2 and SIL3
|
| Communication Supported |
HART (terminals 1 & 2 only)
|
| Electrical Connection |
Crimp ferrules
|
| Power Supply |
20-35 Vdc
|
| Current Consumption |
51mA at 24V
|
| Maximum Safe Voltage |
24 Vdc
|
| Galvanic Isolation |
250V rms between safe-area circuits and power supply
|
| LED Indication |
Yes
|
| LED Color - Power |
Green
|
| Power Dissipation |
1.0W at 24 Vdc
|
| Transfer Accuracy |
Better than 15µA
|
| Temperature Drift |
<0.8µA/°C
|
