20L - 30L Jerrycan Blow Molding Machine Oil Drum Water Bottle Production Line
| Specification | Value |
|---|---|
| Voltage | 380V |
| Clamping Force (kN) | 180 |
| Output (kg/h) | 40 |
| Plastic Processed | PP, HDPE,PE/PP, HDPE/PP |
| Automation | Automatic |
| Power (kW) | 58 |
| Weight (t) | 11.5 |
| Warranty | 1 Year |
| Video Outgoing Inspection | Provided |
| Machinery Test Report | Provided |
| Core Components | PLC, Engine, Bearing, Motor |
| Place of Origin | China |
| Province | Jiangsu |
| Brand Name | ANCO |
| Dimension (L×W×H) | 3600 × 2600 × 2800 |
| PLC Brand | MITSUBISHI |
| Screw L/D Ratio | 25 |
| Screw Diameter (mm) | 90 |
| No. of Screw Heating Zone | 5 |
| Screw Heating Power (kW) | 9 |
| Extruder Motor Power (kW) | 7.5 |
| Mold Platen Size Width (mm) | 680 |
| Mold Platen Size Height (mm) | 600 |
| Air Pressure (MPa) | 0.8 |
| Air Consumption (m³/min) | 0.6 |
| Die Head Heating Power (kW) | 17 |
| Key Selling Points | Long Service Life, Easy to Operate |
- Advanced Mitsubishi PLC control system for precise operation
- High-efficiency extrusion with 40 kg/h production capacity
- Versatile material compatibility including PET, HDPE, and PP
- Robust construction with 180 kN clamping force
- Energy-efficient operation with optimized heating zones
- Easy operation and maintenance for maximum productivity
Zhangjiagang Anco Machinery Equipment Co., Ltd. was established in 2008, headquartered in Zhangjiagang City, Suzhou City, Jiangsu Province. We are an enterprise that integrates research and development, production, sales, and service. Deeply involved in the field of plastic molding equipment, we are committed to providing efficient, energy-saving, and intelligent extrusion blow molding machines to global customers, helping them achieve dual improvements in production efficiency and product quality.
Our innovation-driven development features modular design that supports rapid mold change and flexible production, meeting diverse customer needs. Strict quality control and full process digital testing ensure equipment stability and industry-leading lifespan. We provide 24-hour response, technical training, and spare parts supply. Our products are exported to international markets, and we provide process optimization and equipment upgrade solutions based on customer production needs.
Anco Machinery adheres to the concept of "precision, professionalism, and innovation", insisting on the dual wheel drive of technology research and development and user needs. We always assist partners in success with excellent quality and efficient service, creating sustainable value with our partners.
