Railway Side Dump Wagon 30m3 100km/H Q450NQR1 Material
Price:
60000-80000usd/unit
MOQ:
1unit
Delivery Time:
3-6months
Brand:
Railteco
Product Description
Railway Side Dump Wagons in Bulk Material Handling
Railway Side Dump Wagons
A railway side dump wagon is a specialized type of freight railcar designed to transport bulk materials—such as ore, coal, and rock—and unload them quickly to the side of the tracks. Unlike hopper cars that discharge between the rails, these wagons can dump their entire load to the left or right, making them ideal for construction and mining operations.
Main Parameters
| Loading Capacity | 70T |
| Tare Weight | ≤36T |
| Axle Load | 26.5T |
| Max. Tipping Angle | 45° |
| Volume | 30m³ |
| Design Speed | 120km/h |
| Max. Running Speed | 100km/h |
| Gauge | Can be customized |
| Bogie | Three-piece Type |
| Power of Dump | Compressed Air |
Side Dumping Mechanism
The wagon's body tilts laterally (typically to a 45-degree angle) using pneumatic or hydraulic systems, allowing the load to slide out directly onto the ground beside the railway.
