Lichuan 220V 12NM 3 Phase Nema 34 Closed Loop Stepper Motor Driver With Digital Display
Price:
$172.60-188.30 / piece
MOQ:
1 piece
Delivery Time:
Negotiable
Brand:
Lichuan
Product Description
Lichuan Motor Stepper AC 220V 12NM 3 Phase Nema 34 Closed Loop Stepper Motor Driver With Digital Display For CNC Router Kit
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
Packing List
|
NO.
|
Product Name
|
Model / Description
|
Quantity
|
|
1
|
Nema 34 closed loop stepper motor
|
LC86H3156
|
1
|
|
2
|
Nema 34 closed loop stepper driver
|
LCDA2260E
|
1
|
|
3
|
Driver encoder cable
|
Standard (3m)
|
1
|
Products Description
3 phase 10NM NEMA34 Closed-loop stepper motor driver/ LC86H3156 information
LCDA2260E adopts the latest special motor control DSP chip and vector closed loop control technology, completely solves step missing issues for open loop stepper motor,obviously improves motor performance at high speed, reduces heat generation and vibration of motor, increases processing speed and precision of machine, decreases power consumption. When continuous overload of motor occurs, the Driver will timely output alarm signal, it is as reliable as AC servo system. Applies to motor installation dimensions which are fully compatible with Nema 34/42 series stepper motors, is convenient for upgrading traditional stepper driver solutions and largely reduces cost.
|
Lichuan 3 Phase Digital Hybrid Servo Driver
|
|
|
|
Product Model
|
LCDA2260E
|
|
|
Product Size
|
179.99*139.9*67mm
|
|
|
Product Weight
|
1.22KG
|
|
|
Voltage input range
|
AC 150V~230V
|
|
|
Maximum output current
|
6A
|
|
|
Pulse form
|
Pulse + direction,CW/CCW
|
|
|
Logic input current
|
10~20mA
|
|
|
Pulse corresponding frequency
|
0~200kHz
|
|
|
insulation resistance
|
500MΩ
|
|
|
3 Phase Nema 34 Closed Loop Stepper Motor
|
|
|
|
|
|
|||||
|
Series
|
Step Angle(°)
|
Holding Torque(N.m)
|
Phase Current(A)
|
Length (mm)
|
Weight (kg)
|
|||||
|
LC86H398
|
1.2
|
6.0
|
3.0
|
123
|
3.5
|
|||||
|
LC86H3114
|
1.2
|
6.8
|
3.0
|
140
|
4.2
|
|||||
|
LC86H3129
|
1.2
|
10
|
3.0
|
154
|
4.7
|
|||||
|
LC86H3156
|
1.2
|
12
|
3.0
|
182
|
5.5
|
|||||
