Graphite Resistance Debinding Furnace With Radiation Proof Material Processing
Price:
$ 60000-100000
MOQ:
1 Set
Delivery Time:
90 Days
Brand:
Nuotian
Product Description
Graphite Resistance Debinding Furnace with Radiation Proof material for Industrial Hard Alloy and SiC Sintering Featuring Vacuum Technology and Durable Build
Description:
- Equiped with for non-stop industrial production, this 1-to-1 vacuum type resistance furnace achieves 2200℃ via high-efficiency resistance heating and a sealed vacuum chamber (20Pa ultimate vacuum). Powered by 380V 3-phase electricity with thyristor control, it guarantees stable temperature output even during long production cycles.
- Its heavy-duty industrial structure resists wear from continuous operation, while the intelligent temperature control system precisely calibrates heating rates and holding times to ensure uniform processing of large batches with a long time service. This design minimizes product variance and boosts overall yield for high-demand materials.
- Pairs with automated safety features (vacuum leak detection, over-temperature shutdown, power-off protection) and a streamlined operation panel, it reduces manual labor and operational risks, making it ideal for mass production of PI film, radiation proof material,Rare earthoxide, ceramic material, .
Application:
- Hard Alloy Manufacturing: Large-scale heat treatment of tungsten carbide and rhenium alloy parts for cutting tools and machinery.
- SiC Component Production: Mass sintering of silicon carbide for semiconductor and industrial equipment applications.
- Carbon Material Processing: High-throughput debinding of PI film and radiation-proof materials for industrial supply chains.
Specification:
|
Resistance Furnace -- Technology Parameter |
||||||
|
|
Lab usage |
Production usage |
||||
|
NTI-DZL-54W |
NTI-DZL-98W |
NTI-DZL-300w |
NTI-DZL-400W |
NTI-DZL-720W |
||
|
Working size |
mm |
300×300×600 |
350×350×800 |
500×500×1200 |
500×500×1600 |
600×600×2000 |
|
Heating type |
/ |
Resistance heating |
||||
|
Control type |
/ |
SCR control |
||||
|
HT zone capacity |
L |
54 |
98 |
300 |
400 |
720 |
|
Loading weight |
g |
HT zone capacity ×density(g/cm³)×1000 Remark:1L=1000cm³ |
||||
|
IF power |
Kw |
100 |
150 |
300 |
400 |
650 |
|
Ultimate vacuum |
Pa |
20 |
||||
|
Max.working temperature |
℃ |
2300 |
2300 |
2300 |
2300 |
2300 |
|
Usual working temperature |
℃ |
2200 |
2200 |
2200 |
2200 |
2200 |
|
Temperature uniformity |
℃ |
±10 |
±10 |
±10 |
±10 |
±10 |
|
Working environment |
/ |
Vacuum or Ar, Nitrogen atmosphere protection(micro positive pressure) |
||||
Furnace Configuration:
- Control System: Optional 1-to-1 (one control cabinet for one furnace), equipped with Delta PLC for stable, intelligent operation.
Key standard & optional components:
- Vacuum System: Integrated high-performance vacuum unit (including vacuum pump, valve group) to maintain stable vacuum environment during sintering.
- Gas Purifier: High-efficiency gas purification equipment (optional) to filter impurities and ensure clean gas supply for atmosphere-controlled processes.
- Cooling Tower: Optional cooling equipment to achieve efficient heat dissipation, ensuring stable operation of high-temperature components.
- Temperature Measurement: Equipped with Raytek (US) infrared thermometer for real-time, accurate high-temperature monitoring (supports precise temperature control up to 2200℃).
- Air Compressor: Optional auxiliary equipment to provide stable air supply for pneumatic components.
Feature Advantages:
- High-Temperature Capability: Reaches up to 2200℃.
- Vacuum & Resistance Heating: Vacuum environment prevents material oxidation.
- Precise Control: Equipped with FP93 Japanese Shimaden High-Precise Temperature Control System, ensuring stable sintering processes and consistent product quality.
- Versatility: Compatible with a wide range of materials (carbon,ceramics, alloys, c/c,special powders), meeting diverse production needs.
- Safety & Reliability: Equipped with short circuit, over pressure, over-temperature, over current, water shortage, and other protection mechanisms for safe operation.
![]()
After-sales Service:
We provide comprehensive after-sales support to ensure your equipment operates smoothly:
- Warranty: 1-year warranty for core electrical components against manufacturing defects.
- Lifetime Service: Lifetime technical support, including remote troubleshooting, maintenance guidance, and replacement part supply (charged for non-warranty parts).
- Response Efficiency: 24-hour online consultation for urgent issues; on-site service (available globally) can be arranged based on your needs (travel costs extra).
