Bimetallic High Temp Cutout Switch Thermal Protector Switch 17AM Waterproof

Price Negotiable

Price: please contact us

MOQ: 1000

Delivery Time: 5-7 work days

Brand: HCET

Product Description

17AM Bimetallic Motor High Temp Cutout Switch Thermal Protection Device Waterproof

Product Specifications

Attribute	Value
Product name	17AM thermal protector
Temperature range	50~180℃
Tolerance	±3℃,±5℃
Voltage	250V
Current	<10A
Material	Metal
Feature	Snap action switch
Application	Industrial Motors

Product Description

The HCET 17AM series is a precision-engineered bimetallic thermal overload protector designed for critical motor protection across multiple industries. As a direct replacement for KLIXON 17AM series, it delivers superior temperature-current dual sensitivity with enhanced durability.

Key Features

Dual-Sensing Technology: Simultaneously monitors temperature rise and current overload, providing 360° protection for motor windings against burnout.
Industrial Environment Ready: IP67 sealed housing withstands moisture, oil mist and vibration in pumps, compressors and agricultural equipment.
Cross-Industry Application: HVAC Systems: Safeguards condenser/evaporator motors. Automotive: -40℃~150℃ extreme temp tolerance.
Smart Trip Recovery: Automatic reset after cooling, reducing system downtime in production lines.
Global Certification Ready: Pre-certified for UL/TUV/CE compliance - accelerates OEM product approvals.

Electrical Characteristics

Temperature Range	50℃~180℃ (Customizable temperature, please contact us)
Temperature Tolerance	±3℃, ±5℃
Electrical Specifications	20amps/16volts DC 20amps/125 volts DC 10amps/250volts AC
