Tungsten Powder Rotary Vibrating Sieve 750mm 950mm 1150mm Industrial Vibrating Sieve
Introduction
Rotary vibrating screen uses upright motor as the source of vibration, and it is equipped eccentricity hammer on the both sides of motor. Adjust the phase angle on the both sides of the top and bottom to change the movement orbits of the screen surface. It can be equipped with screen cloth cleaning device to avoid clogging effectively. The vertical horizontal and inclined movement of the machine, the track of materials on the screen can be controlled by adjusting the angle of the two eccentric weights.
- Compact structure, light weight and small footprint.
- The discharge outlet direction is adjustable, with automatic separation and discharge of coarse and fine materials.
- No screen clogging or dust flying; the finest screen available is up to 500 mesh (28 microns), and the finest filter up to 5 microns.
- Single-layer rotary vibrating screen with a unique grid structure ensures long screen service life. Screen replacement is simple and fast, taking only 3–5 minutes, with easy operation and cleaning.
- No mechanical transmission parts, resulting in low maintenance. It can be used in single or multi-layer configuration. All material-contact parts are made of stainless steel (excluding medical-grade applications).
- Suitable for screening various materials within a certain range, including solids, liquids, powders, granules and slurries.
| Model | Power(kw) | Valid Diameter of screen(mm) | Volume(mm) | Layers |
| DY-600-1S DY-600-2S DY-600-3S |
0.55kw | 550mm | 800*800*680 800*800*780 800*800*880 |
1 2 3 |
| DY-800-1S DY-800-2S DY-800-3S |
0.75 kw | 750mm | 900*900*780 900*900*930 900*900*1080 |
1 2 3 |
| DY-1000-1S DY-1000-2S DY-1000-3S |
1.5 kw | 950mm | 1160*1160*880 1160*1160*1030 1160*1160*1180 |
1 2 3 |
| DY-1200-1S DY-1200-2S DY-1200-3S |
1.75 kw | 1150 mm | 1360*1360*980 1360*1360*1160 1360*1360*1360 |
1 2 3 |
| DY-1500-1S DY-1500-2S DY-1500-3S |
2.2 kw | 1450mm | 1850*1850*1130 1850*1850*1330 1850*1850*1550 |
1 2 3 |
| DY-1800-1S DY-1800-2S DY-1800-3S |
3 kw | 1750mm | 2200*2200*1360 2200*2200*1460 2200*2200*1680 |
1 2 3 |
1) Food industry: sugar, salt, alkali, gourmet powder, starch, milk powder, yeast powder, pollen, food additive, bean milk, juice, etc.
2) Chemical industry: resin pigment, medicine, grease, paint, palette, etc.
3) Medicine Industry: Pills, tablets, capsules, granules
4) Abrasive material and ceramic industry
5) The Building industry: sand , cement,Pebble
6) Plastics industry.
7) Organic fertilizer industry.
8) Mechanical industry: casting sand, powder metallurgy, electromagnetic material and metal powder, etc
9) Paper-making industry: coated slurry, exhaust liquid, paper making liquid and waste water reclamation, etc.
Xinxiang Dayong Vibration Equipment Co., Ltd. is a international manufacturing factory with research and development, design, production and sales services, it is committed to providing customers with reasonable and efficient screening, conveying and crushing equipment design solutions. The company have more than 100 employers, and setted with R & D, technology and other departments, of which graduate students, college education accounted for more than 80%. The company is located in Henan, Xinxiang province. The main products are divided into: Fine screening equipment (lab sieve shaker; vibro screen; ultrasonic vibrating screen; flour screen; rotary sifter; liquid sifter; tumbler screener; linear vibrating screen; gyro screen, etc.); Mining screen equipment (roller or trommel screen, circular vibrating screen; heavy linear vibrating screen; probability screen; dewatering sieve; stack sieve etc.) Conveyor equipment (belt conveyor, screw conveyor, bucket elevator, etc.) Crushing equipment (hammer crusher, jaw crusher, etc.) The pruducts has passed the ISO9001 quality system and CE certification, and all the equipment fittings are famous brand in China. The equipment is not only popular in China and have been exported to the United States; Australia; Russia; Britain; Spain; Germany; Japan; Holland; Poland; Turkey; Oman; Philippines; Thailand; Indonesia; Singapore and other countries and regions.
a: Customers who are familiar with technical performance and parameters can directly order.
It appreciate If you send us the pictures you have ever used.
b: Customers who need us to choose the models, please tell us follow the information:
Name and feature of the raw material? Aim of using: get rid of impurity, filtration, grading Handling capacity: kg /h, L/h The raw material size: (mesh or mm) How many final materials you want, or how many layer you need? It appreciate If you send us the relevant pictures about the details.
c: How many kinds of material are supported?
All stainless steel (304, 316L) All carbon steel Q235A Contact part Stainless steel.
d: Is it special requirement available?
Yes, the equipment could be designed according to customer's using aim or special requirements.
