Heavy Duty Screw Conveyor Suitable for Transporting Granular Powder and Bulk Solids in Chemical Food and Agricultural Industries
This screw conveyor is a customizable machine. We can design and manufacture a screw conveyor according to customers' specific requirements. The screw conveyor also be called as other name in different country, for example, sometimes will also named it as pipe screw conveyor; auger conveyor; trough shaped screw conveyor; screw feeder; U-type screw conveyor and so on.
Selection Conditions
Material to be processed: _____
Bulk Density: _____t/m3
Material size:____mm
Handling capacity :_____t/h
Center distance from inlet to outlet:______m
Installation angle: ________°
Working power supply: _____V ______HZ
| Model | Diameter (mm) |
The distance of blades(mm) | Speed (rpm) |
Capacity (t/m³) |
Speed (rpm) |
Capacity (t/m³) |
Speed (rpm) |
Capacity (t/m³) |
Speed (rpm) |
Capacity (t/m³) |
| D | S | n | φ=0.33 | n | φ=0.33 | n | φ=0.33 | n | φ=0.33 | |
| LS100 | 100 | 100 | 140 | 2.2 | 112 | 1.7 | 90 | 1.4 | 71 | 1.1 |
| LS125 | 125 | 125 | 125 | 3.8 | 100 | 3.0 | 80 | 2.4 | 63 | 1.9 |
| LS160 | 160 | 160 | 112 | 7.1 | 90 | 5.7 | 71 | 4.5 | 56 | 3.6 |
| LS200 | 200 | 200 | 100 | 12.4 | 80 | 9.9 | 63 | 7.8 | 50 | 6.2 |
| LS250 | 250 | 250 | 90 | 21.8 | 71 | 17.2 | 56 | 13.6 | 45 | 10.9 |
| LS315 | 315 | 315 | 80 | 38.8 | 63 | 30.5 | 50 | 24.2 | 40 | 13.4 |
- Small size and rapid rotary speed, which ensures rapid and average conveying.
- Good sealing quality and rigidity. The outer casing is made of seamless steel pipes, and the end caps are connected with flanges.
- Modular design and excellent fabricating.
- Inlets and outlets can be configured as required.
- Dust-tight housing, high degree of sanitation.
Loose materials such as powder, granular and small piece material , which includes: clay powder, pulverized coal, cement, sand, grain, small piece of coal , cobble, and cast iron filings, etc. While it is not applicable for materials with high viscosity and easy to be curdled. Widely applied:It is widely used for the loose cement transportation from cement warehouse to mixer or from cement warehouse to compounding machine in concrete mixing plant
- 1).MOQ require?
Our moq is 1 set.(If you need the spare parts,it is also ok). - 2).Payment method?
Usually,we accept T/T,Western Union and others, we can't accept D/P,D/A - 3).How to guarantee the quality?
If any machine quality problems, we accept return cargos.
Our warrantity is 18 months, promise your 0 risks purchasing
