NMC High Energy Density Electric Truck Battery , 47KWh Pickup Truck Battery 136Ah

High Energy Electric Vehicle Batteries For Electric Pick Up Truck ,Logistic Vehicle

This battery pack is designed to provide reliable, high-capacity power for heavy-duty trucks used in transportation and logistics. These batteries are crucial for ensuring the efficiency, range, and performance of electric commercial trucks.

Battery pack capacity :388V136Ah

Voltage range :288-403V

Battery system whole energy 47Kwh

Battery cell capacity :3.6V17Ah

Steady discharging current :170A

Steady discharge overcurrent(A) :300A

Transient charging current (A) : 350A

Transient discharging current (A) :350A

Battery system on Vehicle Waterproof class :IP67

Cooling system :Air cool

Battery cell parameters

Typical Capacity voltage: 3.6V17Ah 1C discharging (25±2 degree)

Charging end of voltage :4.2V

Standard charging and discharging current :0.5C

max continuous charge and discharge current :1C

max pluse charging current :1.5C(15-45 degree) < 30S

max pluse discharging current :3C (15-45 degree) < 30S

Working temperature : Charging:-10~45 degree

Discharging :-20~55 degree

Product Features

High Energy Density:Provides substantial energy storage to power heavy-duty trucks over long distances without frequent recharges.

Integrated Battery Management System (BMS):Protects against overcharge, over-discharge, short circuits, and thermal issues, ensuring safe and efficient battery operation.

Modular and Scalable Design:Can be customized and scaled to meet the specific energy requirements of different truck models and applications

Applications:

Long-Haul Freight Trucks :These trucks are designed for transporting goods over long distances across highways and interstates.

Urban Delivery Trucks:Used for last-mile delivery in urban and suburban areas, typically with frequent stops and starts.

Refrigerated Trucks

Construction and Mining Trucks :Heavy-duty trucks used in construction sites and mining operations for transporting materials and equipment.
