Product introduction

48V 100Ah lithium battery for an electric golf cart is a powerful and efficient energy storage unit designed to provide reliable performance and extended range for the vehicle.

Battery pack specification :

Cell Configuration:  1P16S

Chemistry:                LiFePO4

Capacity:                 51.2V100Ah

Max Charging Voltage:          58.4V

Working Voltage Range:    40 - 58.4V

Max Continuous Discharge current :    200A

Max Charging Current :                        100A Continuous, 300A @ 15s

Max Discharge Peak Current : 300A @ 15s, 700A @ 2s

Series | Parallel:                         Max (2) in Parallel

Charge Temp Range:               0°C / 55°C

Discharge Temp Range:          -20°C / 60°C

Storage Temp:                 0°C  / 35°C (Max 12 Months)

Cycle life  :3,500 Cycle Life

Charger, Fuel Gauge, 12V Converter, Mounting Bracket INCLUDED

Bluetooth (iOS & Android) with Over the Air Firmware Updates

Product Performance

· High discharge rate, providing strong and consistent power output for the golf cart.

· Extended range, enabling longer usage between charges.

· Low self-discharge rate, ensuring the battery retains its charge even during periods of inactivity.

Durability and Safety:

· Built-in Battery Management System (BMS) to monitor and protect against overcharging, over-discharging, short circuits, and overheating.

· Robust construction to withstand vibrations and shocks encountered during golf cart operation.

· Environmentally friendly, with no harmful emissions or pollutants.

Applications:

· Normally the battery pack are used in electric golf carts, utility vehicles, and other low-speed electric vehicles.
