High Endurance Gerotor Hydraulic Motor PGM365 For Vocational Municipal Equipment
High Endurance Hydraulic Gear Motor PGM365 For Vocational Municipal Equipment
Hydraulic Gear Motor Introduction
Hydraulic gear motor PGM365 fixed displacement gear motors offers high performance and high endurance due to its cast iron construction.PGM 365 series fixed displacement gear motors offer high pressure durability due to their cast iron construction, making them ideal for high duty cycle mobile applications for the Construction, Forestry, and Oil & Gas markets. They are available as a standard motor.
Runhe Hydraulics' PGM series of compatible gear motors are 100% compatible replacements for the original PGM series, using the same dimensions, mounting flanges, shaft end specifications, port configurations, and performance parameters, and supporting bidirectional operation. Key features include high pressure resistance, high efficiency, low noise, robustness, durability, and excellent power density, making them suitable for industrial and mobile hydraulic systems.
Hebei Runhe Hydraulic Machinery Co., Ltd. has 12+ years in hydraulics and serves leading domestic OEMs. We offer excavator cylinders matching all big brands, full customization per drawings, plus gear pumps and motors for engineering machinery, agriculture, lifting, ports, automation and intelligent warehousing. Committed to quality survival and integrity growth — join us for win-win success worldwide!
Hydraulic Gear Motor Parameters
|
Product Type: |
Motor, cast iron bushing,external gear |
Operating |
0 to 180 F with standard seals,0 to 150F with FPM seals |
|
Displacement: |
44.3 to 147.5 cm3/rev (Motor), 2.70 to 9.00 inch3/rev (Motor) |
Temperature: |
400 to 3000 RPM |
|
Direction of Rotation: |
Bi-Directional |
Operating Speed: |
15 psig |
|
Mounting Type: |
SAE 2-Bolt or 4-Bolt |
Maximum Inlet Pressure Rating: |
13 cm (5 in) Hg at operating temperature |
|
Shaft Type: |
SAE Splined,Keyed |
Maximum Continuous Vacuum Pressure: |
up to 241 bar, up to 3500 psi |
|
Shaft Seal Material: |
NBR,FPM [FKM], NBR,FPM [FKM] |
Continuous Outlet Pressure: |
56 lbs with 1"gear Add 1 lb each additional 1/4" of gear, 56 lb |
|
Number of Ports: |
BSPP, Metric Split Flange,SAE Straight Thread or Split Flange |
For Fluid Type: |
Fire Resistant Fluids:Water-Oil Emulsions 60/40,HFB; Water-Glycol,HFC; Phosphate Esters,HFD,Mineral Oil |
|
Speed RPM |
T-Torque: In.-lbs./ Nm F-Flow: GPM/LPM |
|||||||
|
1’’ |
1-1/4’’ |
1-1/2’’ |
1-3/4’’ |
|||||
|
245bar |
245bar |
245bar |
225bar |
|||||
|
F |
T |
F |
T |
F |
T |
F |
T |
|
|
900 |
70 |
210.7 |
83 |
266.1 |
97 |
323.1 |
111 |
380.8 |
|
18.4 |
1865 |
22 |
2355 |
25.6 |
2860 |
29.2 |
3370 |
|
|
1200 |
88 |
208.5 |
106 |
263.3 |
124 |
319.7 |
142 |
376.8 |
|
23.3 |
1845 |
28.1 |
2330 |
32.9 |
2830 |
37.6 |
3335 |
|
|
1500 |
107 |
205.1 |
129 |
259.3 |
152 |
314.1 |
174 |
370.6 |
|
28.2 |
1815 |
34.1 |
2295 |
40.1 |
2780 |
46 |
3280 |
|
|
1800 |
125 |
203.9 |
152 |
257.6 |
179 |
312.4 |
206 |
368.9 |
|
33.1 |
1805 |
40.2 |
2280 |
47.3 |
2765 |
54.4 |
3265 |
|
|
2100 |
144 |
198.3 |
175 |
250.8 |
206 |
303.9 |
238 |
357 |
|
37.9 |
1755 |
46.2 |
2220 |
54.4 |
2690 |
62.8 |
3160 |
|
|
2400 |
162 |
192.6 |
198 |
243.5 |
234 |
295.5 |
269 |
345.2 |
|
42.8 |
1705 |
52.3 |
2155 |
61.7 |
2615 |
71.2 |
3055 |
|
|
Speed RPM |
T-Torque: In.-lbs./ Nm F-Flow: GPM/LPM |
|||||
|
2’’ |
1-3/4’’ |
2’’ |
||||
|
210bar |
190bar |
175bar |
||||
|
F |
T |
F |
T |
F |
T |
|
|
900 |
124 |
435 |
138 |
454.2 |
152 |
466.1 |
|
32.9 |
3850 |
36.5 |
4020 |
40.1 |
4125 |
|
|
1200 |
160 |
430.5 |
179 |
449.7 |
197 |
461 |
|
42.4 |
3810 |
47.2 |
3980 |
52 |
4080 |
|
|
1500 |
197 |
423.7 |
219 |
442.3 |
242 |
454.2 |
|
52 |
3750 |
57.9 |
3915 |
63.8 |
4020 |
|
|
1800 |
233 |
421.4 |
260 |
440.1 |
287 |
451.4 |
|
61.5 |
3730 |
68.6 |
3895 |
75.7 |
3995 |
|
|
2100 |
269 |
407.9 |
300 |
426 |
332 |
436.7 |
|
71.1 |
3610 |
79.3 |
3770 |
87.6 |
3865 |
|
|
2400 |
305 |
394.3 |
341 |
411.8 |
377 |
422.6 |
|
80.6 |
3490 |
90.1 |
3645 |
99.5 |
3740 |
|
Hydraulic Gear Motor Application
- Tire Trucks
- Salt and sand spreaders
- Aerial Lift
- Low boy trailers
- Live (Moving) Floor Trailers
- Roll Off Trailers
Hydraulic Gear Motor Advantage
- Three-piece cast iron construction for distribution flexibility
- Cast Iron construction for durability
- Balanced Thrust Plates minimize friction and leakage
- Journal bearings for long life
- Multiple sections available
