TCK50Y Y-axis CNC Slant Bed Lathe with 500mm Max Processing Length and 50mm Max Bar Diameter
Price:
10800-12500
MOQ:
1
Delivery Time:
30 working days
Brand:
Matsumoto
Product Description
TCK50Y Multiple Configurations Available CNC Slant Bed Lathe Machine
Description:
The TCK50Y is a high-performance Y-axis slant bed CNC turning center (mill-turn lathe) for complex multi-process machining in one setup. Its 45° one-piece HT300 cast iron slant bed ensures strong rigidity and vibration damping for stable cutting.
| Specification | Unit | TCK50Y | |
| Processing range | Max. swing over bed | mm | 550 |
| Max. processing diameter(axis/chuck) | mm | 260/460 | |
| Max. processing length | mm | 500 | |
| Max. bar diameter | mm | 50 | |
| Travel | X-axis travel | mm | 250 |
| Z-axis travel | mm | 500 | |
| Spindle | Output power | kw | 7.5/11 |
| Spindle end form | - | A2-6 | |
| Spindle speed | r/min | 35-3000 | |
| Spindle bore diameter | mm | 66 | |
| Clamp | Three-jaw chuck | - | 10 inch hollow chuck |
| Tailstock | Tailstock sleeve diameter/travel | mm | 480 |
| Tailstock sleeve taper hole | Morse | 5 | |
| Guide rail screw | Guide rail specifications | mm | P series RG35 |
| Screw specifications | mm | 3210/4010 | |
| Speed | Fast moving speed X/Z | m/min | 24 |
| Cutting feed speed | mm/min | 5000 | |
| Tool holder | Tool holder form | - | Servo turret |
| Tool blade size | mm | 25 | |
| Tool capacity | set | 12 | |
| Max. boring tool diameter | mm | 32 | |
| Machine accuracy | Positioning accuracy(X-axis) | mm | 0.008 |
| Positioning accuracy(Z-axis) | mm | 0.013 | |
| Repeat positioning accuracy(X-aixs) | mm | 0.005 | |
| Repeat positioning accuracy(Y-axis) | mm | 0.006 | |
| Others | CNC system | - | Guangzhou CNC 980TB3i |
| Cutting fluid tank volume | L | 200 | |
| Machine overall size | mm | 2697*1795*1860 | |
| Machine tool G.W. | kg | 3900 | |
Usages:
The TCK50Y Y-axis mill-turn lathe is mainly used for one-stop machining of complex medium-sized parts, capable of completing multiple operations without re-clamping, including:
-
External and internal turning of shafts, discs and irregular parts
-
Y-axis offset machining (off-center drilling, milling, tapping)
-
Face milling, side drilling and tapping of workpieces
-
Precision contouring and thread machining
