High Precision Iron Removal Liquid Magnetic Separators Strength ≥13000 GS For New Energy Material
New Energy Material Specialized Liquid Pipeline Iron Remover | High-Precision Iron Removal | Magnetic Field Strength ≥13000 GS
Product Overview
High-precision liquid pipeline iron remover specially designed for the new energy materials industry. Magnetic field strength up to 15,000 Gauss, iron removal precision 0.01mm, suitable for high-purity materials such as lithium battery cathode slurries and electrolytes.
Technical Parameters
|
Parameter Item |
Technical Specifications |
|---|---|
|
Pipe Diameter Specifications |
Φ150×25 to Φ300×200 mm |
|
Magnetic Field Strength |
≥13000 GS |
|
Working Pressure |
≤10 kg/cm² |
|
Iron Removal Precision |
0.01 mm |
|
Material Selection |
304/316L Stainless Steel |
|
Surface Treatment |
Food Grade Polishing |
|
Magnetic Rod Type |
Permanent/Electromagnetic Optional |
|
Number of Magnetic Rods |
1-15 rods |
|
Suitable Temperature |
≤80°C |
|
Cleaning Method |
Easy-to-clean Type |
|
Control Method |
PLC Automatic Control |
Application Scenarios
-
Lithium Battery Materials: Iron removal from cathode and anode slurries
-
Electrolyte: Iron removal from lithium-ion battery electrolytes
-
Photovoltaic Materials: Iron removal from silicon materials, slurries
-
Fuel Cells: Iron removal from catalyst slurries
-
Energy Storage Materials: Iron removal from electrode materials
Core Advantages
-
High-Precision Iron Removal: Iron removal precision 0.01mm
-
High Magnetic Field Strength: Up to 15,000 Gauss
-
Clean Production: No contamination risk
-
Online Monitoring: Real-time monitoring of iron removal effectiveness
-
Quick Replacement: Modular design, fast maintenance
-
Intelligent Control: PLC automatic control system
Economic Benefits
-
Improve material purity: Meets high-purity requirements
-
Enhance battery performance: Extends cycle life
-
Reduce production costs: Decreases scrap rate
-
Improve production efficiency: Continuous online iron removal
-
Quick return on investment: 6-10 months payback period
QA
Q1: What level of iron removal precision can be achieved?
A: Can remove fine iron powder above 0.01mm.
Q2: Is it suitable for lithium battery materials?
A: Specifically designed for lithium battery cathode slurries, electrolytes, etc.
Q3: How does the equipment ensure cleanliness?
A: 316L stainless steel material, food-grade polishing, dead-end free design.
Q4: Does it support online monitoring?
A: Equipped with PLC control system, supports real-time monitoring.
