4-20mA Loop power supply HART transmission signal GS5031-EX GS5032-EX
Price:
Negotiable
MOQ:
5 sets
Delivery Time:
Negotiable
Brand:
chenzhu
Product Description
4-20mA Loop Power Supply with HART Transmission Signal - GS5031-EX GS5032-EX
This analog input and output isolation barrier provides isolated power supply for transmitters in hazardous areas while isolating and transmitting current signals from hazardous to safe sides. It also enables bidirectional transmission of HART digital signals, making it ideal for closed-loop power supply systems in DCS and PLC applications.
Technical Specifications| Specification | GS5035-EX | GS5036-EX | GS5045-EX |
|---|---|---|---|
| Number of channels | 1 in, 2 out | 2 in, 2 out | 1 in, 1 out |
| Response time | 2ms reaches 90% of final value | 2ms reaches 90% of final value | 2ms reaches 90% of final value |
| Input signal | 0-20mA; 4-20mA; HART digital signal | 0-20mA; 4-20mA; HART digital signal | 0-20mA; 4-20mA; HART digital signal |
| Open-circuit voltage | ≤28V | ≤28V | ≤28V |
| Distribution voltage | Voltage at 20mA: ≥15.5V | Voltage at 20mA: ≥15.5V | Voltage at 20mA: ≥15.5V |
| Normal operating current | ≤25mA | ≤25mA | ≤25mA |
| Output signal | 0-20mA; 4-20mA; HART digital signal; 0-5V; 1-5V | 0-20mA; 4-20mA; HART digital signal; 0-5V; 1-5V | 0-20mA; 4-20mA; HART digital signal; 0-5V; 1-5V |
| Current output load resistor | RL≤300Ω (550Ω optional) | RL≤300Ω (550Ω optional) | RL≤300Ω (550Ω optional) |
| Voltage output load resistor | RL 330 kΩ or higher | RL 330 kΩ or higher | RL 330 kΩ or higher |
| Supply voltage (Ue) | 20-35V DC | 20-35V DC | 20-35V DC |
| Power protection | Reverse power supply protection | Reverse power supply protection | Reverse power supply protection |
| Current consumption | ≤75mA (at 24V with 20mA output) | ≤75mA (at 24V with 20mA output) | ≤75mA (at 24V with 20mA output) |
| Power supply mode | Independent power supply | Independent power supply | Independent power supply |
| Power connection method | Terminal power supply | Terminal power supply | Terminal power supply |
| Material | PA | PA | PA |
| Protection grade | IP20 | IP20 | IP20 |
About Bailui Electric Technology Co., Ltd.
Established in January 2013, Bailui Electric Technology Co., Ltd. specializes in sensor product R&D, design, production, and trade. With over a decade of technological expertise, we follow a "technology first, service first" business philosophy to provide comprehensive application solutions for pharmaceutical, aerospace, chemical, and electronics industries. With extensive foreign trade experience, we offer competitive pricing, short production cycles, and satisfactory after-sales service. We welcome partnerships with customers worldwide for mutual development and benefit.
Frequently Asked Questions
What's your idea about your offer?
We have our own factory and offer high-quality products at competitive prices.
What's the MOQ?
The minimum order quantity is one piece, with pricing based on quantity for larger orders.
What type of payment do you have available?
We accept TT and L/C for sample orders, with Western Union, MoneyGram, and Aliexpress also available.
What's the delivery time?
7-10 days after payment confirmation.
How to make an order?
Provide us with the required size and quantity, or describe your application so our technicians can recommend the appropriate specifications. After payment, we will arrange production and expedite delivery.
