Energy Saving Modular Submersible Mixers Wastewater Treatment Corrosion Resistant
Submersible Mixer: Used for flow pushing, mixing and stirring, and gentle stirring in biological treatment systems.
Quick Details
|
Submersible Mixer for Water Treatment |
|
Power Supply Voltage: AC 200~400V, optional |
|
Power Supply Frequency: 50/60Hz |
|
Equipment Power: 0.37–30+kW, optional |
|
Temperature Range: 1–40℃ |
|
Material: 304/316 stainless steel or carbon steel + anti-corrosion coating |
|
Customizable on Demand |
Product Overview
This series of submersible mixers is a high-efficiency, energy-saving and fully submerged power mixing equipment specially designed for water and wastewater treatment processes. It highly integrates the motor, reduction gear and hydraulic impeller, and operates completely submerged in the liquid. By generating powerful axial flow or mixed flow, it realizes push-flow circulation, uniform mixing, sedimentation prevention and mass transfer enhancement in the process tank. As a core underwater power equipment in modern wastewater treatment plants, its reliability and efficiency are directly related to the stable operation and energy consumption indicators of the overall process.
High-efficiency Hydraulic Model: The impeller adopts Computational Fluid Dynamics (CFD) optimized design, which ensures the generation of maximum fluid propulsion or mixing intensity with minimal power consumption, achieving the optimal flow pattern and energy ratio (kW/m³·s).
High Reliability
Dual Mechanical Seal System: Adopts an independent, oil-chamber lubricated double mechanical seal to strictly prevent water from infiltrating into the motor cavity, ensuring absolute safety for long-term underwater operation.
Top IP68 Protection Class: The motor has Class F insulation, providing the highest underwater protection standard and adapting to all-weather continuous operation.
Corrosion-resistant Structure: All wetted parts are mainly made of AISI 304/316L stainless steel, or high-strength carbon steel coated with epoxy resin/polyurethane heavy-duty anti-corrosion layer, perfectly coping with corrosive and abrasive media.
Low Maintenance & Long Service Life
Lifetime Lubricated Bearings: Maintenance-free design greatly reduces downtime and maintenance costs.
Modular Design: Key components such as cable inlets and seal systems are modularized, facilitating quick on-site inspection and replacement.
Overheat Protection: PTC thermistors and humidity sensors are built into the motor windings and connected to the control cabinet, realizing real-time monitoring and alarm for overheating, overload and leakage.
The mixer is available in multiple installation modes including fixed type, movable type (guide rod lifting system) and floating type, suitable for new construction or renovation projects. The cable uses a sewage-resistant and tear-resistant flexible rubber sheathed cable, equipped with a special waterproof connector.
Product Series and Application Scenarios
We offer a full range of solutions to meet diverse requirements from municipal sewage to industrial wastewater treatment:
|
Series Type |
Main Impeller Form |
Core Functions |
Typical Application Scenarios |
|
Propulsive Flow Series |
High-efficiency Swept-back Propeller |
Generates strong directional jet flow to drive long-distance water circulation. Key parameters: Thrust (N), Service Volume (m³). |
Oxidation ditches, anaerobic tanks, anoxic tanks, river water circulation, large-scale aeration tanks, anti-icing. |
|
Mixing/Agitation Series |
Three-blade/Four-blade Turbine, Curved Surface Impeller |
Creates high-turbulence mixing or gentle agitation to ensure suspension and mass transfer. Key parameters: Power Density (W/m³), Velocity Gradient (G-value). |
Rapid mixing tanks (coagulants), flocculation tanks, sludge homogenization tanks, sludge thickening tanks, digestion tanks, chemical neutralization tanks. |
|
Low-speed Large Impeller Series |
Large-diameter Curved Surface Impeller |
Produces a wide range of gentle flow fields at extremely low speeds to prevent sedimentation and save energy. |
Sludge collection in secondary sedimentation tanks, large-scale storage tanks, gentle agitation in biological tanks. |
Technical Specifications
|
Motor Power: 0.37 kW to above 30 kW (standard range). |
|
Impeller Diameter: 180 mm to 1200 mm+, optimally matched according to tank type and function. |
|
Rated Voltage: 200-400V 3Ph 50/60Hz or other customized voltages. |
|
Speed Range: Fixed speed as standard; two-speed or variable frequency drive (VFD) options available for intelligent energy-saving control. |
|
Standard Configuration: Impeller and mixing shaft - AISI 304 stainless steel; mounting system - hot-dip galvanized carbon steel. |
|
Optional Upgrades: AISI 316L stainless steel, duplex stainless steel, carbon steel with full epoxy/polyurethane coating. |
|
Design Standards: Compliant with international electrical and mechanical safety standards such as ISO, CE, and IEC. |
