China High Precision Male Rod End Bearing 5-80mm Bore Size for Packaging Industry for sale

High Precision Male Rod End Bearing 5-80mm Bore Size for Packaging Industry

Price Negotiable

Price: $0.5 - $50.00

MOQ: 500pcs

Delivery Time: 30 days

Brand: SYX

Product Description

Rod Ends Requiring Maintenance Male Rod End Bearing SI 5E up to SI 80 ES GAR 5 GAR 80 DO

Rod Ends Requiring Maintenance are sliding bearings designed for regular lubrication through external oil nozzles or nipples. These bearings withstand medium to high loads in continuous high-frequency mechanical operations, providing long-term stable performance. Continuous lubrication reduces friction and wear, extending service life, making them ideal for industrial applications where frequent part replacement is challenging.

Product Features and Structure

Lubrication Method: Equipped with lubricating oil nozzles (oil cups) for regular manual or automatic lubrication system maintenance, ensuring continuous lubrication of sliding surfaces
Material Composition: Typically constructed from carbon structural steel bodies with bearing inner and outer rings featuring lubricating oil grooves. Some models utilize quenched bearing steel for inner rings to enhance wear resistance
Bearing Capacity: Capable of withstanding radial loads and axial loads in any direction not exceeding 0.2 times the radial load, suitable for swinging and tilting movements
Working Conditions: Ideal for applications with medium to high loads, frequent reciprocating motion, and significant environmental temperature changes, including construction machinery, hydraulic cylinders, and automation equipment

Available Sizes

5mm to 80mm diameter range

Bearing Code	Dimensions (mm)										Load Rating kN		a°	Weight
	d	B	dk	C1	d2	d3	h	L1	L2	L7	Dynamic	Static	a°	≈kg
	d	B	dk	max	max	6H	h	min	max	L7	Dynamic	Static	≈
SA5E	5	6	10	4.5	21	M5x0.8	36	16	46.5	11.5	3.4	3.9	13	0.017
SA6E	6	6	10	4.5	21	M6x1	36	16	46.5	11.5	3.4	5.5	13	0.017
SA8E	8	8	13	6.8	24	M8x1.25	42	21	54	13	5.5	10	15	0.029
SA10E	10	9	16	7.5	29	M10x1.5	48	26	62.5	15	8.1	16	12	0.050
SA12E	12	10	18	8.5	34	M12x1.75	54	28	71	18	10	23	10	0.066
SA15ES	15	12	22	10.5	40	M14x 2	63	34	83	21	16	32	8	0.120
SA15ES 2RS	15	12	22	10.5	40	M14x 2	63	34	83	21	16	32	8	0.120
SA17ES	17	14	25	11.5	46	M16x2	69	36	92	24	21	44	10	0.190
SA17ES 2RS	17	14	25	11.5	46	M16x2	69	36	92	24	21	44	10	0.190
SA20ES	20	16	29	13.5	53	M20x1.5	78	43	104.5	25.5	30	60	9	0.310
SA20ES2RS	20	16	29	13.5	53	M20x1.5	78	43	104.5	25.5	30	60	9	0.310
SA25ES	25	20	35.5	18	64	M24x2	94	53	126	31	48	83	7	0.560
SA25ES 2RS	25	20	35.5	18	64	M24x2	94	53	126	31	48	83	7	0.560
SA30ES	30	22	40.7	20	73	M30x2	110	65	146.5	35.5	62.2	110	6	0.890
SA30ES 2RS	30	22	40.7	20	73	M30x2	110	65	146.5	35.5	62.2	110	6	0.890
SA35ES	35	25	47	22	82	M36x3	140	82	181	41	79	146	6	1.400
SA35ES 2RS	35	25	47	22	82	M36x3	140	82	181	41	79	146	6	1.400
SA40ES	40	28	53	24	92	M39x3	150	86	196	47	99	180	7	1.800
SA40ES 2RS	40	28	53	24	92	M39x3	150	86	196	47	99	180	7	1.800
SA45ES	45	32	60	28	102	M42x3	163	92	214	52	127	240	7	2.500
SA45ES 2RS	45	32	60	28	102	M42x3	163	92	214	52	127	240	7	2.500
SA50ES	50	35	66	31	112	M45x3	185	104	241	60	156	290	6	3.600
SA50ES 2RS	50	35	66	31	112	M45x3	185	104	241	60	156	290	6	3.600
SA60ES	60	44	80	39	135	M52x3	210	115	277.5	75.5	245	450	6	5.700
SA60ES 2RS	60	44	80	39	135	M52x3	210	115	277.5	75.5	245	450	6	5.700
SA70ES	70	49	92	43	160	M56x4	235	125	315	95	313	610	6	7.900
SA70ES 2RS	70	49	92	43	160	M56x4	235	125	315	95	313	610	6	7.900
SA80ES	80	55	105	48	180	M64x4	270	140	360	105.5	400	750	6	12.000
SA80ES 2RS	80	55	105	48	180	M64x4	270	140	360	105.5	400	750	6	12.000

For left-hand thread, suffix "L" is added to bearing number and thread sign, e.g. SAL20ES M20x1.5L-6H.

SA..ES is equivalent to GAR..DO INA.

Industrial Applications

Specifically designed for packaging industry applications requiring reliable, maintenance-friendly bearing solutions

Application examples of rod end bearings in packaging machinery systems
